QuickSpecs
Overview
1.
Power button (with integrated power indicator light)
2.
Flash drive activity indicator light
3.
Audio connector (headphone/speaker out)
4.
Audio connector (mic in)
5.
USB connectors (two)
6.
Removable stand for vertical orientation
7.
Mounting points for HP Quick Release or other VESA mount
8.
Secure USB compartment cover
9.
Cable lock slot (secures unit and secure USB compartment)
Front
DA - 13496 North America — Version 15 — February 21, 2013
1.
Cabling exit from secure USB compartment
2.
Wi-Fi antenna connector (depends on model)
3.
Ethernet RJ-45 connector
4.
USB connectors (four)
5.
DisplayPort monitor connector
6.
VGA monitor connector
7.
PS-2 keyboard connector
8.
PS-2 mouse connector
9.
Serial connector
10.
+19V DC power input
11.
Power cable retention slot
12.
Mounting location for four (4) horizontal mounting feet
HP t5740 Thin Client
Back
Page 1

Advertisement

loading

Related Manuals for HP t5740

Summary of Contents for HP t5740

  • Page 1 USB connectors (two) DisplayPort monitor connector Removable stand for vertical orientation VGA monitor connector Mounting points for HP Quick Release or other VESA mount PS-2 keyboard connector Secure USB compartment cover PS-2 mouse connector Cable lock slot (secures unit and secure USB compartment)
  • Page 2 5. USB connectors (two) USB 2.0 connectors (four) 6. Removable stand for vertical orientation DisplayPort monitor connector 7. Mounting points for HP Quick Release or other VESA mount PCIe/PCI slot access 8. Secure USB compartment - 2 USB connectors VGA monitor connector 9.
  • Page 3 HP Easy Tools including: The HP Easy Update utility that makes it quick and easy to identify and choose the latest image and add-on settings helping get up, running and productive faster than ever before. Exclusive HP ThinState Tools offers in-box, easy-to-use image deployment and recovery tools...
  • Page 4 QuickSpecs HP t5740 Thin Client Overview Protected by Hewlett-Packard Services, including a limited three-year mail-in warranty (certain restrictions and exclusions apply) DA - 13496 North America — Version 15 — February 21, 2013 Page 4...

  • Page 5: Standard Features - Models

    Microsoft Internet Explorer 7 Client Management HP Device Manager agent HP Client Automation agent Software HP ThinState for image capture and redeploy Keyboard USB or PS/2 (varies by region) Mouse USB or PS/2 (varies by region) Product complies with U.S. Trade Agreement (TAA). Available in U.S only.
  • Page 6 Microsoft Internet Explorer 7 Client Management HP Device Manager agent HP Client Automation agent Software HP ThinState for image capture and redeploy Keyboard USB or PS/2 (varies by region) Mouse USB or PS/2 (varies by region) Product complies with U.S. Trade Agreement (TAA). Available in U.S only.
  • Page 7 Graphics HP DisplayPort to DVI-D Adapter FH973AA FH973AT Storage HP 16GB SATA II IDE Solid State Flash Drive (for secondary storage) AZ550AA HP USB External CD/DVD R/RW Drive (read only support) FS943AA FS934UT Apacer 4GB AH522 USB 2.0 Flash Drive 91.HDE2S.HP00C...
  • Page 8 OS image or in a hardware or software RAID configuration. Remote Management tools may manage content on the secondary storage drive, but cannot be used to install the thin client OS image onto this drive. Additional HP OS Image tools including but not limited to ThinState Capture, RAMDisk Manager, and the write filters will not function or support the secondary storage drive.

  • Page 9: Technical Specifications

    QuickSpecs HP t5740 Thin Client Technical Specifications Memory Configurations Flash Memory Memory Slot 1 (DDR-3) Memory Slot 2 (DDR-3) 2 GB 1 GB Empty 2 GB 2 GB Empty 4 GB 2 GB Empty Processor Intel Atom N280 1.66 GHz...
  • Page 10 Provision Networks (Quest) broker Management HP Device Manager agent HP ThinState for rapid deployment HP Easy Tools GUI (avail as add-on) guides you through initial setup and configurations DA - 13496 North America — Version 15 — February 21, 2013 Page 10...
  • Page 11 UL 1950, CSA 950; TÜV-GS (EN60 950) approved RF Interference FCC Class B; CE Mark; EN55022B; VCCI Warranty Three-year limited hardware warranty. NOTE: Certain restrictions apply. Consult the HP Customer Support Center for details. Emulations Emulation Terminal ID ADDS A2...
  • Page 12 QuickSpecs HP t5740 Thin Client Technical Specifications SCO Console Stratus V102 TA6530 TVI910 TVI920 TVI925 TVI950 TVI955 VT52, VT100, VT100+, VT100, VT101, VT102, VT125, VT131, VT132, M2200, VT220, VT240, VT320, VT500 (7- or 8-bit) VT340, VT420, VT510, VT520, VT525 VT HP220,...

  • Page 13: Technical Specifications - Environmental Data

    European Union Restriction Products and Approach of Hazardous Substances (RoHS) Directive. HP's goal is to exceed compliance obligations by meeting the requirements of the RoHS Directive on a worldwide basis. By July 1, 2006, RoHS substances will be virtually eliminated (virtually = DA - 13496 North America —...
  • Page 14 HP t5740 Thin Client Technical Specifications – Environmental Data to levels below legal limits) for all HP electronic products subject to the RoHS Directive, except where it is widely recognized that there is no technically feasible alternative (as indicated by an exemption under the EU RoHS Directive).
  • Page 15 © 2013 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice and is provided "as is" without warranty of any kind. The warranties for HP products and services are set forth in the express limited warranty statements accompanying such products and services.
