Setup Utility-Integrated Peripherals - HP st5742 - Streaming Client Troubleshooting Manual

Table 4-4 Setup Utility—Advanced BIOS Features (continued)
3rd Boot Device
Boot Up Numlock
Status
Security Option
POST Delay (secs)
F12 Boot
Setup Utility—Integrated Peripherals
Table 4-5
Option
Integrated Audio
Network Controller
WLAN Controller
USB Controller
Advanced USB
Options
USB Keyboard
Support
USB Mouse Support
Serial Port 1
Serial Port 2
Parallel Port
Parallel Mode
ECP Mode Use DMA
26 Chapter 4 BIOS Settings, (F10) Utility
Select Boot Device Priority. Default is Network.
Select power on state for Numlock. Default is Off.
Select whether the Password is required every time the system boots or only when you enter
Setup. Default is Setup.
Set a delay that is added to POST to allow more time to press
Default is None.
Enable/Disable F12 network boot. Default is Enabled.
Setup Utility—Integrated Peripherals
Description
Enable or Disable Onboard AC97 Audio controller. Default is Enabled.
Enable or Disable Onboard LAN device. Default is enabled.
Enable or Disable wireless LAN device. Default is enabled.
Enable or Disable USB controller. Default is enabled.
Enable or Disable Secure USB and/or external ports. Default is enabled.
Allows use of USB keyboard under DOS. Default is enabled.
Allows use of USB Mouse under DOS. Default is disabled.
Select serial port base IO port address and IRQ. Default is 3F8/IRQ4.
Select serial port base IO port address and IRQ. Default is 2F8/IRQ3.
Select parallel port base IO port address and IRQ. Default is 378/IRQ7.
Select parallel port transfer mode of Standard, EPP, ECP, or ECP/EPP. Default is ECP/EPP.
Select DMA channel of 1 or 3 if parallel is operated in ECP mode. Default is 3.
F10 to enter the Setup Utility.
