Appendix A Specifications - HP st5742 - Streaming Client Troubleshooting Manual

A Specifications
Table A-1
Dimensions
Width (front to back)
Height (top to bottom, without stand)
Depth (side to side)
Approximate Weight
Temperature Range (fanless design)*
Operating**
(max. rate of change is 10° C per hour or 18° F per hour)
Nonoperating
(max. rate of change is 20° C per hour or 36° F per hour)
*Specifications are at sea level with altitude derating of
1° C/300m (1.8° F/1000ft) to a maximum of 3Km
(10,000ft), with no direct, sustained sunlight. Upper limit
may be limited by the type and number of options
installed.
Relative Humidity (non-condensing)
Operating
(max. wet bulb temperature is 28° C or 84.2° F)
Nonoperating
(max. wet bulb temperature is 38.7° C or 101.6° F)
Maximum Altitude (unpressurized)
Operating
(max. allowed rate of change is 457m per minute or 1500
ft per minute)
Nonoperating
(max. allowed rate of change is 457m per minute or 1500
ft per minute)
36

Appendix A Specifications

HPt5740/t5745 Thin Client
222 mm 8.74 in.
255 mm 10.04 in
44 mm 1.73 in.
1.53 kg 3.37 lb
10° to 40° C 50° to 104° F
-30° to 60° C -22° to 140° F
** The operating temperature range when the thin
client is attached to a flat panel using the HP Quick
Release is 50° to 95° F (10° to 35° C).
10–90% 10–90%
5–95% 5–95%
10,000 ft
3048 m
30,000 ft
9,144 m
