4. Push the module into the socket, ensuring that the module is fully inserted and properly seated.
5. Press the module down into the compartment.
6. Replace the access plate:
a. Insert the tab on the front edge into its slot and set the plate into position.
NOTE:
the chassis.
b. Replace the two screws to secure the access plate to the chassis.
7. Slide the serial number tab into its slots.

Installing the PCI Express Expansion Module and PCI Express Card

Before beginning the replacement process, review
on page 7 for procedures you should follow before and after installing or replacing hardware.
WARNING!
power cord is disconnected from the electrical outlet.
Follow the installation instructions included in the PCIe Expansion Module option kit.

External Drives

Various external USB drives are available as options for the t5740/t5745. For more information about
these drives, visit http://h10010.www1.hp.com/wwpc/us/en/sm/WF12a/12454-12454-321959.html, or
refer to the instructions that accompany the option.
For more information about available options, visit the HP Web site at
wwpc/us/en/sm/WF12a/12454-12454-321959.html.
You may need to press lightly on the access plate to position it properly against
Before removing the side access panel, ensure that the thin client is turned off and the
General Hardware Installation Sequence
http://h10010.www1.hp.com/
Installing Thin Client Options 17
