NOTE:
8. Replace the side access panel and metal side cover. See
Access Panel and Metal Side Cover on page 10
9. Install the stand, if you will be using the thin client unmounted in a vertical orientation. See
Installing the Stand on page 5
10. Replace the secure USB compartment cover. See
Compartment Cover on page 8
11. Reconnect any external devices and power cords.
12. Turn on the monitor, the thin client, and any devices you want to test.
13. Load any necessary drivers.
NOTE:
eng/support.html.
Removing and Replacing the Secure USB Compartment
Cover
The secure USB compartment allows you to install two USB devices in a secure location inside the
thin client. Along with providing a hidden location, the secure USB compartment can be locked by the
optional security cable lock.
CAUTION:
(131° F) in worst case conditions. Make sure the specifications for any device you install in the
compartment indicate the device can tolerate a 55° C (131° F) ambient environment.
NOTE: In addition to following these instructions, follow the detailed instructions that accompany the
accessory you are installing.
Before beginning the installation process, review
for procedures you should follow before and after installing or replacing hardware.

Removing the Secure USB Compartment Cover

Use the following procedure to remove the secure USB compartment cover.
WARNING!
turned off and the power cord is disconnected from the electrical outlet.
To remove the secure USB compartment cover:
1. On rear of the thin client, remove the screw that secures the compartment cover to the unit (1).
2. On the front of the unit, push the compartment cover about 1.27 cm (1/2 inch) toward the front of
the unit (2).
8 Chapter 2 Hardware Changes
Installing a Secondary Flash Memory Module on page 14
Installing a Second SO-DIMM on page 15
Option kits include more detailed installation instructions.
You can download select hardware drivers from HP at
The ambient temperature inside of the secure USB compartment can reach up to 55° C
Before removing the secure USB compartment cover, ensure that the thin client is
for more information.
for more information.
Removing and Replacing the Secure USB
for more information.
General Hardware Installation Sequence on page 7
Removing and Replacing the Side
http://www.hp.com/country/us/
