Modem Module - HP 4410t - Mobile Thin Client Maintenance And Service Manual

Removal and replacement procedures

Modem module

✎
The modem module spare part kit does not include a modem module cable. The modem module cable is
included in the Cable Kit, spare part number 536538-001. See
module cable removal information.
Description
Modem module
Before removing the modem module, follow these steps:
1. Shut down the computer.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet, and then
unplugging the AC adapter from the computer.
4. Remove the battery (see
5. Remove the following components:
a. Switch cover (see
b. Keyboard (see
c. Optical drive (see
d. Speakers (see
e. Palm rest (see
f. Solid-state module (see
g. Top cover (see
4–24
"Battery" on page
"Switch cover" on page
"Keyboard" on page 4-9)
"Optical drive" on page
"Speakers" on page 4-15)
"Palm rest" on page 4-16)
"Solid-state module" on page
"Top cover" on page 4-22)
"Modem module cable" on page 4-28
4-7).
4-8)
4-13)
4-20)
for modem
Spare part
number
510100-001
Maintenance and Service Guide
