System board

✎
The system board spare part kit includes replacement thermal material.
Description
System board
Before removing the system board, follow these steps:
1. Shut down the computer.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet, and then
unplugging the AC adapter from the computer.
4. Remove the battery (see
5. Remove the following components:
a. Switch cover (see
b. Keyboard (see
c. Optical drive (see
d. Speakers (see
e. Palm rest (see
f. Solid-state module (see
g. Top cover (see
h. Heat sink (see
i. Display assembly (see
When replacing the system board, be sure that the following additional components are removed from the defective
system board and installed on the replacement system board:
■
Memory modules (see
■
WLAN module (see
■
Modem module (see
■
RTC battery (see
■
Processor (see
■
Power connector cable (see
Maintenance and Service Guide
"Battery" on page
"Switch cover" on page
"Keyboard" on page
"Optical drive" on page
"Speakers" on page 4-15)
"Palm rest" on page 4-16)
"Solid-state module" on page
"Top cover" on page
"Heat sink" on page 4-29)
"Display assembly" on page
"Memory module" on page
"WLAN module" on page
"Modem module" on page
"RTC battery" on page
"Processor" on page 4-34)
"Power connector cable" on page
4-7).
4-8)
4-9)
4-13)
4-20)
4-22)
4-37)
4-12)
4-18)
4-24)
4-26)
4-43)
Removal and replacement procedures
Spare part
number
578179-001
4–41
