Right-side components

Item Component
(1) USB ports (2)
(2) RJ-11 (modem) jack
(3) Optical drive (select models only)
(4) Optical drive light (select models only) Blinking: The optical drive is being accessed.
(5) Battery light
(6) Power connector
Maintenance and Service Guide
Description
Connect optional USB devices.
Connects a modem cable.
Reads optical discs and, on select models, also writes to optical discs.
■ Amber: A battery is charging.
■ Turquoise: A battery is close to full charge capacity.
■ Blinking amber: A battery that is the only available power source has
reached a low battery level. When the battery reaches a critical battery
level, the battery light begins blinking rapidly.
■ Off: If the computer is plugged into an external power source, the light turns
off when all batteries in the computer are fully charged. If the computer is
not plugged into an external power source, the light stays off until the
battery reaches a low battery level.
Connects an AC adapter.
External component identification
2–9
