Picker-Slot Calibration
1. From the Available Tests list, select Picker Slot Calibration: Long Axis (as shown in
Figure 33 on page 24).
2. Select Prepare Test.
3. Select Run Test (there are no parameters for this test).
This test will calibrate the top and bottom location of each tape pack by loading
the tape in Slot 1 and Slot 15 of each data cartridge magazine.
4. Watch to see that each first and fifteenth slot loads correctly.
The tape will be returned to the E/E port when the test is completed.
Note:
This test takes a long amount of time to complete. It could take up
to an hour in a fully-loaded Spectra 64K library.
5. Check the test results.
The test may indicate that retries were made, which is normal.
Caution:
Make sure that there are no slots that fail to load. If a slot fails,
contact Spectra Logic Technical Support at (800) 227-4637 or at
(303) 449-0160.
6. Return to the Inventory screen.
7. Select Open/Close to open the E/E port.
8. Remove the tape from the library.
9. Select Open/Close to close the E/E port.
