Remove the Spectra E/E Port Slider

Note:
The Spectra 64K library has one E/E port motor for each E/E port.
The motor for the top E/E port is located on the top of that E/E
port; the motor for the bottom E/E port is located on the bottom of
that E/E port. Only remove the E/E port motor that is attached to
the slider you are replacing.
1. Make sure the E/E port door is closed.
2. Disconnect the E/E port motor from both the power source and the motor cables
(Figure 13 and Figure 14).
Figure 13 The E/E port motor power source and motor
cables (Spectra 12K library shown).
Entry/Exit Port Slider Replacement Guide
Figure 14 The E/E port motor power source and motor
cables (Spectra 64K library shown).
