3. Using the appropriate screwdriver, remove the three screws holding the motor in
place (Figure 15 and Figure 16).
Note:
Some libraries built before September 2000 may have four screws
attaching the motor to the E/E port. If your motor is installed with
four screws, call Spectra Logic Technical Support at (800) 227-4637
or (303) 449-0160. Inform the support representative that you are
installing an E/E port motor in a Spectra 12K or Spectra 64K
library, and your E/E port motor has four screws attaching it to the
E/E port. Spectra Logic Technical Support will provide you with
information to complete the motor removal.
Figure 15 The three E/E port motor screws (Spectra
12K library shown).
4. Pull the motor either straight down or straight up as appropriate, and set the motor
aside.
Entry/Exit Port Slider Replacement Guide
Figure 16 The three E/E port motor screws (Spectra
64K library shown).
