Replace the E/E Port Slider

1. Remove the new E/E port slider from its packaging. Make sure to remove the
plastic clips holding the slider in place (Figure 22).
2. Place the slider in carefully and replace the Stop.
Caution:
Do not move the E/E port without holding on to the slider. The
slider is equipped with ball bearings that may fall out if the
slider and E/E port are removed separately.
3. Replace the five screws that hold the slider in place using the same method you
used to remove the original slider. Refer to Figure 18 for location of the five screws.
4. Replace the nine magazines you removed. Make sure that they are replaced in the
reverse order in which they were removed.
Entry/Exit Port Slider Replacement Guide
Figure 22 Remove slider from packaging and make sure to
remove the plastic clips (identified in picture).
