Page 1: Installation Guide
Installation Guide 613-000287 Rev D Intelligent Multiservice Gateways AT-EN646 AT-iMG646BD-ON AT-iMG646PX-ON... - Page 2 Allied Telesis, Inc. has been advised of, known, or...
- Page 3 Electrical Safety and Emissions Standards This product meets the following standards. Declaration of Conformity Manufacturer Name: Allied Telesis, Inc. Declares that the product(s): Multiservice Gateways Model Numbers: AT-iMG646BD-ON, AT-iMG646PX-ON This product complies with FCC Part 15B, Class B Limits: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device must not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 4 Translated Safety Statements Important: The indicates that a translation of the safety statement is available in a PDF document titled “Translated Safety Statements” posted on the Allied Telesis website at www.alliedtelesis.com.
-
Page 5: Table Of Contents
Preface ... 11 Safety Symbols Used in this Document ... 12 Where to Find Web-based Guides ... 13 Contacting Allied Telesis ... 14 Online Support ... 14 Email and Telephone Support... 14 Returning Products ... 14 For Sales or Corporate Information... 14 Warranty... - Page 6 Contents Preparing and Connecting the Power Cord... 58 Mounting the Splice Tray on the Gateway... 60 Connecting the Fiber Optic Cable ... 61 Connecting the Telephone Wires ... 62 Connecting the LAN Cables ... 63 Completing the Installation ... 65 Section II: Indoor Installation ...67 Chapter 5: Installing the Gateway Indoors ...
- Page 7 Figures Figure 1. AT-iMG646xx Series Intelligent Multiservice Gateway...20 Figure 2. Gateway LEDs ...21 Figure 3. AT-EN646 Enclosure...26 Figure 4. Mounting Hole Locations ...33 Figure 5. Grounding Plate ...35 Figure 6. Aligning the Grounding Plate...35 Figure 7. Location of Fiber Optic Drop Cable and Ground Wire Entrance ...36 Figure 8.
- Page 8 Figures Figure 51. Proper Installation of the Terminal Block Ground Wire...79 Figure 52. Plugging in the DC Terminal Block ...80 Figure 53. Connecting the Fiber Optic Cable...81 Figure 54. Connecting the Telephone Wires ...82 Figure 55. Connecting the LAN Cables ...83 Figure 56.
- Page 9 Tables Table 1. Safety Symbols ...12 Table 2. PWR, SYST, and LAN LEDs ...21 Table 3. WAN LED on the ATiMG646BD-ON ...22 Table 4. WAN LED on the ATiMG646PX-ON ...22 Table 5. Gateway Terminal Block to Power Cord Terminal Block Wiring ...90...
- Page 10 Tables...
-
Page 11: Preface
Preface This guide contains instructions on how to install the AT-EN646 enclosure and an AT-iMG646xx series intelligent Multiservice Gateway. This preface contains the following sections: “Safety Symbols Used in this Document” on page 12 “Where to Find Web-based Guides” on page 13... -
Page 12: Safety Symbols Used In This Document
Preface Safety Symbols Used in this Document This document uses the safety symbols defined in Table 1. Symbol Table 1. Safety Symbols Meaning Caution Performing or omitting a specific action may result in equipment damage or loss of data. Warning Performing or omitting a specific action may result in electrical shock. -
Page 13: Where To Find Web-Based Guides
AT-iMG646xx Series Intelligent Multiservice Gateway and AT-EN646 Enclosure Installation Guide Where to Find Web-based Guides The installation and user guides for all Allied Telesis products are available in portable document format (PDF) on our web site at www.alliedtelesis.com. You can view the documents online or download... -
Page 14: Contacting Allied Telesis
Email and For Technical Support via email or telephone, refer to the Allied Telesis web site: www.alliedtelesis.com. Select your country from the list Telephone displayed on the website. Then select the appropriate menu tab. -
Page 15: Management Software Updates
Allied Telesis web site: www.alliedtelesis.com Allied Telesis FTP server: ftp://ftp.alliedtelesis.com If you prefer to download new software from the Allied Telesis FTP server from your workstation’s command prompt, you will need FTP client software and you must log in to the server. Enter “anonymous” for the user name and your email address for the password. - Page 16 Preface...
-
Page 17: Chapter 1: Overview
Chapter 1 Overview This chapter contains the follows sections: “Features” on page 18 “LEDs” on page 21... -
Page 18: Features
Chapter 1: Overview Features The AT-iMG646xx-ON gateway is optimized for delivery of IP Triple Play services. With full routing and multicast capabilities, the AT-iMG646xx-ON gateway simultaneously delivers high quality IP video, up to four lines of VoIP, and differentiated data services. Security for the service provider and subscriber are ensured through Stateful-Inspection Firewall and NAT. - Page 19 AT-iMG646xx Series Intelligent Multiservice Gateway and AT-EN646 Enclosure Installation Guide Up to 100Mbps bandwidth delivery In addition to the common features listed above, the AT-iMG646PX-ON model has a 1 Gigabit PX20 802.11ah bidirectional uplink (WAN) port. The AT-iMG646PX-ON WAN interface is compliant with the IEEE 802.3ah EPON standard.
-
Page 20: Figure 1. At-Img646Xx Series Intelligent Multiservice Gateway
Chapter 1: Overview Figure 1 illustrates the AT-iMG646xx series intelligent Multiservice Gateway. Figure 1. AT-iMG646xx Series Intelligent Multiservice Gateway The MAC address(es) for the AT-iMG646xx gateway are located on the label above the RJ11 and RJ45 ports. The AT-iMG646BD-ON has a single MAC address. The AT-iMG646PX-ON gateway has two MAC addresses, one for the GEPON WAN uplink (GEPON WAN MAC or GEPON MAC), and the other for the AT-iMG646PX-ON gateway itself (Ethernet iMG MAC or iMG MAC). -
Page 21: Leds
The AT-iMG646xx series intelligent Multiservice Gateway has four LEDs, as shown in Figure 2 and three of which are described in Table 2. SYST VOIP AT-iMG646xx Series Intelligent Multiservice Gateway and AT-EN646 Enclosure Installation Guide Figure 2. Gateway LEDs Table 2. PWR, SYST, and LAN LEDs State... -
Page 22: Table 3. Wan Led On The Atimg646Bd-On
Chapter 1: Overview The operation of the WAN LED varies depending upon the unit, as described in Table 3 and Table 4. State State Solid Amber Solid Green Table 3. WAN LED on the ATiMG646BD-ON Description A WAN link has not been established. A WAN link has been established. -
Page 23: Section I: Outdoor Installation
Section I Outdoor Installation The chapters in this section provide information and procedures for installing the enclosure and the gateway in an outdoor location. The chapters include: Section I: Outdoor Installation Chapter 2, ”Outdoor Installation Overview” on page 25 Chapter 3, ”Installing the Enclosure” on page 29 Chapter 4, ”Installing the Gateway Outdoors”... - Page 24 Section I: Outdoor Installation...
-
Page 25: Chapter 2: Outdoor Installation Overview
Chapter 2 Outdoor Installation Overview This chapter provides and overview of the outdoor installation and contains the following sections: Section II: Indoor Installation “Enclosure” on page 26 “Installation Options” on page 27... -
Page 26: Enclosure
Chapter 2: Outdoor Installation Overview Enclosure The AT-EN646 enclosure houses and protects the AT-iMG646xx series gateway and is designed to be mounted on the exterior of a building. The features of the enclosure include: Figure 3 illustrates the AT-EN646 enclosure. -
Page 27: Installation Options
You can install the gateway and enclosure in either of the following two sequences: Section II: Indoor Installation AT-iMG646xx Series Intelligent Multiservice Gateway and AT-EN646 Enclosure Installation Guide Install the enclosure first, and the gateway later. In this situation, you can use the instructions in the guide that was shipped with the enclosure, or the instructions in the next chapter of this guide. - Page 28 Chapter 2: Outdoor Installation Overview Section II: Indoor Installation...
-
Page 29: Chapter 3: Installing The Enclosure
Chapter 3 Installing the Enclosure This chapter describes how to install the enclosure and contains the following sections: Section I: Outdoor Installation “Reviewing Safety Precautions” on page 30 “Required Tools and Supplies” on page 32 “Mounting the Enclosure” on page 33 “Installing the Grounding Plate”... -
Page 30: Reviewing Safety Precautions
Note indicates that a translation of the safety statement is available in a PDF document titled “Translated Safety Statements” on the Allied Telesis website at www.alliedtelesis.com. Warning: Do not work on equipment or cables during periods of lightning activity. Warning: Operating Temperature. This product is designed for an operating temperature range of -40°... - Page 31 AT-iMG646xx Series Intelligent Multiservice Gateway and AT-EN646 Enclosure Installation Guide All installation methods shall be in accordance with national and local regulations and practices. The wiring method should include the use of Listed wire/cable acceptable for the application per the National Code, and should be one that an Authority Having Jurisdiction (AHJ) can approve per the Code.
-
Page 32: Required Tools And Supplies
Chapter 3: Installing the Enclosure Required Tools and Supplies The following tools and supplies are required to install the enclosure: Tools Have the following tools on hand before you install the enclosure or gateway: Additional You may also need the following supplies: Supplies 3/8”... -
Page 33: Mounting The Enclosure
Store the packaging material in a safe location. You must use the original shipping material if you need to return the unit to Allied Telesis. package. If any item is missing or damaged, contact your Allied Telesis sales representative for assistance. AT-EN646 enclosure This installation guide Accessory kit that contains the grounding plate;... - Page 34 Chapter 3: Installing the Enclosure 5. Use #8 or larger hardware to mount the enclosure on the wall. Make sure that the enclosure is square to the surface. If it is not, shim with washers to prevent warping. Section I: Outdoor Installation...
-
Page 35: Installing The Grounding Plate
3. Align the notch in the grounding plate with the vertical support, and the 4. Use the self-tapping screw to secure the grounding plate to the Section I: Outdoor Installation AT-iMG646xx Series Intelligent Multiservice Gateway and AT-EN646 Enclosure Installation Guide screw from the accessory kit. Gateway Mounting Post... -
Page 36: Installing The Fiber Optic Drop Cable
Chapter 3: Installing the Enclosure Installing the Fiber Optic Drop Cable This section contains procedures for installing two types of drop cables: Installing the This section contains the following procedures for installing a dielectric drop cable: Dielectric Drop Cable Securing the Fiber Optic Drop Cable To install the dielectric fiber optic drop cable, perform the following procedure: 1. -
Page 37: Figure 8. Inserting The Wire Tie
11. Position the cable so that the strength members go under the strength Section I: Outdoor Installation AT-iMG646xx Series Intelligent Multiservice Gateway and AT-EN646 Enclosure Installation Guide of the entrance as shown in Figure 8. Figure 8. Inserting the Wire Tie entrance. -
Page 38: Installing The Ground Wire
Chapter 3: Installing the Enclosure 12. Tighten the Kepnuts on the strength member clamp to between 10 and 13. Replace the bar, washers, and Kepnuts on the posts of the drop cable Installing the Ground Wire The AT-iMG646 gateway must be connected to a good earth ground. To install the ground wire, perform the following procedure: 1. -
Page 39: Securing The Tracer Wire And Aramid Yarn
2. Loosen the nut on the tracer wire post (see Figure 5 on page 35). Section I: Outdoor Installation AT-iMG646xx Series Intelligent Multiservice Gateway and AT-EN646 Enclosure Installation Guide Kepnut, as shown in Figure 11. Figure 11. Lining Up the Ground Wire the wire tie around the cords and cutting off the excess wire tie. -
Page 40: Installing The Armored Drop Cable
Chapter 3: Installing the Enclosure 3. Wrap the tracer wire around the base of the post under the washer. 4. Trim the yarn back to the post. Installing the To install the armored drop cable, perform the following procedure:. Armored Drop Cable 1. -
Page 41: Figure 14. Inserting The Wire Tie
9. Locate the strength member clamp (see Figure 5 on page 35) on the Section I: Outdoor Installation AT-iMG646xx Series Intelligent Multiservice Gateway and AT-EN646 Enclosure Installation Guide of the entrance as shown in Figure 8. Figure 14. Inserting the Wire Tie entrance. -
Page 42: Figure 16. Positioning The Cable
Chapter 3: Installing the Enclosure 10. Position the cable so that the opened shielding goes under the 11. Tighten the Kepnuts on the strength member clamp to between 10 and 12. Replace the bar, washers, and Kepnuts on the posts of the drop cable strength member clamp and the closed portion of the cable is about .25 in. -
Page 43: Figure 18. Lining Up The Ground Wire
6. Seal the grommet with tape (not provided) and silicone sealant (not 7. Connect the other end of the ground wire to the building’s grounding Section I: Outdoor Installation AT-iMG646xx Series Intelligent Multiservice Gateway and AT-EN646 Enclosure Installation Guide All Countries: Install product in accordance with local and National Electrical Codes. -
Page 44: Splicing The Drop Cable And Securing The Fusion Splice Tray
Chapter 3: Installing the Enclosure Splicing the Drop Cable and Securing the Fusion Splice Tray Locate the fusion splice tray package in the accessory kit. Your kit will contain one of two splice tray versions: a two-part metal tray, or a single- part plastic tray. -
Page 45: Figure 20. Inserting The Wire Ties
4. Route the buffer tube from the drop cable to the lower left corner of the Section I: Outdoor Installation AT-iMG646xx Series Intelligent Multiservice Gateway and AT-EN646 Enclosure Installation Guide lower mounting tabs on the bottom portion, as shown in Figure 20. -
Page 46: Figure 22. Setting The Fiber Cable In The Splice Tray
Chapter 3: Installing the Enclosure 5. Route the fiber cable 1-1/2 times around the splice tray to the splice 6. Cut the SC/UPC pigtail cable (not provided) 29.25 in. (74.30 cm) 7. Strip the SC/UPC pigtail jacket to expose 13.75 in. (39.93 cm) of fiber. 8. -
Page 47: Figure 24. Securing The Metal Splice Tray
12. Temporarily secure the splice tray to the inside of the inner cover with Section I: Outdoor Installation AT-iMG646xx Series Intelligent Multiservice Gateway and AT-EN646 Enclosure Installation Guide electrical tape until the gateway is installed, as shown in Figure 24. -
Page 48: Using The Plastic Splice Tray
Chapter 3: Installing the Enclosure 13. Close the inner door, verifying that the cables are not pinched, and 14. Secure the enclosure until it is time to install the gateway and other Using the Plastic To use the plastic (single-part) splice tray, perform the following procedure: Splice Tray 1. -
Page 49: Figure 27. Setting The Fiber Cable In The Splice Tray
9. Trim the wire ties close to the cables. Section I: Outdoor Installation AT-iMG646xx Series Intelligent Multiservice Gateway and AT-EN646 Enclosure Installation Guide organizer and cut it to a length that will allow the splice to be placed in the organizer, as shown in Figure 27. -
Page 50: Figure 29. Securing The Plastic Splice Tray
10. Temporarily secure the splice tray to the inside of the inner cover with electrical tape until the gateway is installed, as shown in Figure 29. Note In cold climates, Allied Telesis recommends that you use 3M 3723 Cold Temp Tape. 1184 Figure 29. -
Page 51: Chapter 4: Installing The Gateway Outdoors
Chapter 4 Installing the Gateway Outdoors This chapter describes how to install the gateway in the enclosure and contains the following sections: Section I: Outdoor Installation “Reviewing Safety Precautions” on page 52 “Required Tools and Supplies” on page 54 “Installing the Gateway” on page 55 Note You must install the enclosure before you install the gateway. -
Page 52: Reviewing Safety Precautions
PDF document titled “Translated Safety Statements” on the Allied Telesis website at www.alliedtelesis.com. Warning: Class 1 Laser product. Warning: To prevent electric shock, do not remove the cover. - Page 53 AT-iMG646xx Series Intelligent Multiservice Gateway and AT-EN646 Enclosure Installation Guide Warning: This unit is intended for installation in a restricted access location. A restricted access location is where access can only be gained by authorized service personnel through the use of a special tool, lock and key, or other means of security, and is controlled by the authority responsible for that location.
-
Page 54: Required Tools And Supplies
Chapter 4: Installing the Gateway Outdoors Required Tools and Supplies The following tools and supplies are required to install the gateway: Tools Have the following tools on hand before you install the enclosure or gateway: Additional You may also need the following supplies: Supplies You will need the following items to create a ground wire for the DC terminal block:... -
Page 55: Installing The Gateway
Store the packaging material in a safe location. You must use the original shipping material if you need to return the unit to Allied Telesis. package. If any item is missing or damaged, contact your Allied Telesis sales representative for assistance. An AT-iMG646xx series gateway... -
Page 56: Figure 30. Location Of The Mounting Post
Chapter 4: Installing the Gateway Outdoors 3. Open the outer and inner doors of the enclosure and locate the 4. Place the gateway into the enclosure with the mounting post through gateway mounting post, as shown in Figure 30. Mounting Post Figure 30. -
Page 57: Figure 32. Securing The Gateway To The Mounting Post
6. Mount the gateway in the enclosure with four self-tapping pan head Section I: Outdoor Installation AT-iMG646xx Series Intelligent Multiservice Gateway and AT-EN646 Enclosure Installation Guide accessory kit, as shown in Figure 32, hand tightening the lock nut until it is snug. -
Page 58: Preparing And Connecting The Power Cord
Power Cord the manufacturer’s instructions included in the package. Allied Telesis provides a 15 ft. power cord (part number AT-RG013). Alternatively, you can make custom length power cord. The terminal adapters are supplied with the AT-iMG005G UPS and the gateways. For lengths up to 50 ft., use three pair twisted wire with a minimum 18 AWG. -
Page 59: Figure 35. Proper Installation Of The Terminal Block Ground Wire
10. Insert the ground wire into pin 5 alongside the black wire under the pin Section I: Outdoor Installation AT-iMG646xx Series Intelligent Multiservice Gateway and AT-EN646 Enclosure Installation Guide Caution To prevent electrical shock, ensure that the power cord is not connected to the UPS. -
Page 60: Mounting The Splice Tray On The Gateway
Chapter 4: Installing the Gateway Outdoors 11. Pull on both wires at pin 5 to ensure that they are securely fastened to 12. Plug the other end of the power cord into the UPS. 13. Verify the resistance of the ground wire using a Digital Multimeter. 14. -
Page 61: Connecting The Fiber Optic Cable
1. Remove the dust plug from the fiber optic port on the gateway and Section I: Outdoor Installation AT-iMG646xx Series Intelligent Multiservice Gateway and AT-EN646 Enclosure Installation Guide on the front of the gateway and mount the tray to the gateway with four short pan head machine screws from the accessory kit, as shown in Figure 37. -
Page 62: Connecting The Telephone Wires
Chapter 4: Installing the Gateway Outdoors 2. Connect the pigtail cable from the splice tray to the fiber port, using the Connecting the To connect the telephone wires, perform the following procedure: Telephone Wires 1. Remove the grommet from the telephone wire entrance as shown in the receive sensitivity specification. -
Page 63: Connecting The Lan Cables
Figure 41, at 5.3 in-lbs. Figure 41. Connecting the Telephone Wires provided). sealant (not provided). Note Allied Telesis recommends that you fully wire all six ports to allow for easy service expansion in the future. -
Page 64: Figure 42. Lan Cable Entrance
Chapter 4: Installing the Gateway Outdoors 1. Remove the grommet from the LAN cable entrance, as shown in 2. Insert a UV-rated wire tie (not provided) through the slots at the bottom Note Do not connect the Ethernet cables to the gateway until the unit has completed its bootup sequence. -
Page 65: Completing The Installation
4. If necessary, plug the management cable into the console port, as Section I: Outdoor Installation AT-iMG646xx Series Intelligent Multiservice Gateway and AT-EN646 Enclosure Installation Guide secure the wires with a wire tie, as shown in Figure 44. Figure 44. Connecting the LAN Cables cables and reinsert the grommet. - Page 66 Chapter 4: Installing the Gateway Outdoors 5. Configure the AT-iMG646xx series gateways according to your 6. Ensure that all provisioned services are functioning properly. 7. Close and secure the inner and outer doors. Note For networks with remote management enabled, no local configuration is required.
-
Page 67: Section Ii: Indoor Installation
Section II Indoor Installation The chapter in this section provide information and procedures for installing the gateway in an indoor location: Section II: Indoor Installation Chapter 5, ”Installing the Gateway Indoors” on page 69... - Page 68 Section II: Indoor Installation...
-
Page 69: Chapter 5: Installing The Gateway Indoors
Chapter 5 Installing the Gateway Indoors This chapter describes how to install the gateway in an indoor location and includes the following sections: Section II: Indoor Installation “Reviewing Safety Precautions” on page 70 “Required Tools and Supplies” on page 72 “Preparing for the Installation”... -
Page 70: Reviewing Safety Precautions
Note indicates that a translation of the safety statement is available in a PDF document titled “Translated Safety Statements” (613-000405) on the Allied Telesis website at www.alliedtelesis.com. Warning: Class 1 Laser product. Warning: To prevent electric shock, do not remove the cover. - Page 71 AT-iMG646xx Series Intelligent Multiservice Gateway and AT-EN646 Enclosure Installation Guide Warning: This unit is intended for installation in a restricted access location. A restricted access location in where access can only be gained by authorized service personnel through the use of a special tool, lock and key, or other means of security, and is controlled by the authority responsible for that location.
-
Page 72: Required Tools And Supplies
Chapter 5: Installing the Gateway Indoors Required Tools and Supplies The following tools and supplies are required to install the gateway: Tools Have the following tools on hand before you install the enclosure or gateway: Additional You may also need the following supplies: Supplies You will need the following items to create a ground wire for the DC terminal block:... -
Page 73: Preparing For The Installation
Store the packaging material in a safe location. You must use the original shipping material if you need to return the unit to Allied Telesis. package. If any item is missing or damaged, contact your Allied Telesis sales representative for assistance. An AT-iMG646xx series intelligent multiservice gateway... -
Page 74: Fastening The Plywood Mounting Surface To A Wall And Preparing The Gateway
Chapter 5: Installing the Gateway Indoors Fastening the Plywood Mounting Surface to a Wall and Preparing the Gateway For an indoor installation, the AT-iMG646xx series intelligent multiservice gateway must be mounted on a plywood surface that complies with the following specifications: To fasten the plywood to the wall, perform the following procedure: 1. -
Page 75: Figure 47. Putting The Washer On The Stud
8. Secure the stud with its washer to the gateway grounding hole with a Section II: Indoor Installation AT-iMG646xx Series Intelligent Multiservice Gateway and AT-EN646 Enclosure Installation Guide split ring washer. grounding hole in the gateway, as shown in Figure 47. -
Page 76: Figure 49. Securing The Gateway To The Mounting Surface
Chapter 5: Installing the Gateway Indoors 9. Secure the gateway to the mounting surface with the four wood screws provided, starting with the upper right corner, as shown in Figure 49. 1174 Figure 49. Securing the Gateway to the Mounting Surface Section II: Indoor Installation... -
Page 77: Connecting The Ground Wire
3. Secure the ring lug on the stud with a washer and #10-32 Kepnut, as 4. Trim and connect the other end of the ground wire to any ground point Section II: Indoor Installation AT-iMG646xx Series Intelligent Multiservice Gateway and AT-EN646 Enclosure Installation Guide ground connection. into the ground wire ring lug. -
Page 78: Preparing And Connecting The Power Cord
Allied Telesis provides a 15 ft. power cord (part number AT-RG013). Alternatively, you can make custom length power cord. The terminal adapters are supplied with the AT-iMG005G UPS and the gateways. For lengths up to 50 ft., use three pair twisted wire with a minimum 18 AWG. -
Page 79: Figure 51. Proper Installation Of The Terminal Block Ground Wire
11. Verify the resistance of the ground wire using a Digital Multimeter. Section II: Indoor Installation AT-iMG646xx Series Intelligent Multiservice Gateway and AT-EN646 Enclosure Installation Guide Caution To prevent shorting out the unit, ensure that all of the wire strands are twisted tightly together. -
Page 80: Figure 52. Plugging In The Dc Terminal Block
Chapter 5: Installing the Gateway Indoors ohm. If it is not, disconnect the power cable, repeat steps 8 through 11, and re-test. 12. Plug the terminal block into the DC power socket, as shown in Figure 52. 1175 Figure 52. Plugging in the DC Terminal Block Section II: Indoor Installation... -
Page 81: Connecting The Fiber Optic Cable
2. Connect the pigtail cable to the fiber optic port on the gateway, as Section II: Indoor Installation AT-iMG646xx Series Intelligent Multiservice Gateway and AT-EN646 Enclosure Installation Guide clean the port and connector. (See Appendix B, “Cleaning Fiber Optic Connectors” on page 91 for information.) -
Page 82: Connecting The Telephone Wires
Chapter 5: Installing the Gateway Indoors Connecting the Telephone Wires To connect the telephone wires, perform the following procedure: 1. Connect the telephone wires to each pair of telephone terminal posts on the gateway, as shown in Figure 54. 1177 Figure 54. -
Page 83: Connecting The Lan Cables
Section II: Indoor Installation AT-iMG646xx Series Intelligent Multiservice Gateway and AT-EN646 Enclosure Installation Guide Note Allied Telesis recommends that you fully wire all six ports to allow for easy service expansion in the future. Note Do not connect the Ethernet cables to the gateway until the unit has completed its bootup sequence. -
Page 84: Completing The Installation
Chapter 5: Installing the Gateway Indoors Completing the Installation To complete the installation, perform the following procedure: 1. Install an uninterruptible power supply according to the manufacturer’s 2. Plug the power cable from the gateway into the UPS. 3. Turn on the UPS. 4. -
Page 85: Section Iii: Troubleshooting
Section III Troubleshooting The chapter in this section provides information and procedures for troubleshooting the gateways. The chapter is: Chapter 7, ”Troubleshooting” on page 87 Section III: Troubleshooting... - Page 86 Section III: Troubleshooting...
-
Page 87: Chapter 7: Troubleshooting
Plug a POTS telephone into the RJ-11 jack. If the VOIP LED lights up when you lift the receiver, then there may be a problem with the telephone cable. If the VOIP LED does not light up, then there may be a problem with the AT-iMG646BD-ON gateway. Contact Allied Telesis. Section I: Troubleshooting... - Page 88 Check the telephone or fax machine for problems. Note If you need further assistance, please contact Allied Telesis Technical Support. Refer to “Contacting Allied Telesis” on page 14. Section I: Troubleshooting...
-
Page 89: Appendix A: Technical Specifications
Input Supply Voltage: Power Consumption:10W typical, 18W max Safety and Electromagnetic Emissions Certifications EMI/RFI: AT-EN646 330 mm x 230.7 mm x 43.2 mm (12.99 in x 9.08 in x 1.7 in) AT-iMG646BD-ON 305 mm x 218 mm x 25 mm (12.0 in x 8.6 in x 1.0 in) -
Page 90: Power Cord Wiring
Appendix A: Technical Specifications Immunity: Electrical Safety: Power Cord Wiring To wire the terminal block for the gateway to the terminal block for the power supply cord, refer to Figure 57 and Table 5. Gateway Terminal Block Figure 57. Gateway Terminal Block to Power Cord Terminal Block Wiring Table 5. -
Page 91: Appendix B: Cleaning Fiber Optic Connectors
Appendix B Cleaning Fiber Optic Connectors The fiber optic connector consists of a fiber optic plug and its adapter. The end of the fiber optic cable is held in the core of the ferrule in the plug. Light signals are transmitted through the core of the fiber. Even minor smudges or dirt on the end face of the fiber, completely invisible to the naked eye, can disrupt light transmission and lead to failure of the component or of the entire system. -
Page 92: Using A Cartridge-Type Cleaner
Appendix B: Cleaning Fiber Optic Connectors Using a Cartridge-Type Cleaner Fiber optic cartridge cleaners are available from many vendors and are typically called “cartridge cleaners,” as shown in Figure 60. To clean a fiber optic connector using a cartridge cleaner, perform the following procedure. - Page 93 AT-iMG646xx Series Intelligent Multiservice Gateway and AT-EN646 Enclosure Installation Guide Note Rub the ferrule tip on the cleaning surface in one direction only. 9. When you reach the end of the cleaning surface, pick up the ferrule tip, rotate and place it at the top and rub downwards at least 2 times.
-
Page 94: Using A Swab
Appendix B: Cleaning Fiber Optic Connectors Using a Swab Specially treated swabs (stick cleaners) are available for cleaning inside connector adapters or hard-to-reach ferrule tips. These swabs, often referred to as “lint free” or “alcohol free” swabs, are available from many vendors, as shown in Figure 62. - Page 95 AT-iMG646xx Series Intelligent Multiservice Gateway and AT-EN646 Enclosure Installation Guide 3. If a fiber inspection scope is available, use the scope to inspect the connector to make sure that it is clean and to check for scratches, pits, or other problems that may affect performance.
- Page 96 Appendix B: Cleaning Fiber Optic Connectors...
-
Page 97: Appendix C: Turnup Process
The power up and upgrade sequence is detailed in a separate turnup document. Please contact your Allied Telesis sales representative for more information. The gateway bootup sequence is: This process is also shown in the flowchart on the next page. -
Page 98: Turnup Flowchart
Appendix C: Turnup Process Turnup Flowchart The following flowchart provides an overview of the bootup and upgrade process that the AT-iMG646 gateway goes through when it is first introduced into a network.
