Summary of Contents for Allied Telesis AT-IMG616RF/RF+
- Page 1 AT-iMG616RF/RF+ INSTALLATION GUIDE...
- Page 2 Allied Telesis has been advised of, known, or should have known, the possibility of such damages.
-
Page 3: Table Of Contents
Contents MPORTANT SAFETY INSTRUCTIONS ... 7 MPORTANT NOTICE 1.1..7 MISSION TATEMENT ONTENTS OF THE PACKAGE 2.1. MG616RF/RF+ HAT CAN THE ... 10 RODUCT ETAILS 3.1..10 OP VIEW OF 3.2..12 RONT VIEW OF UNIT 3.3..12 IDE VIEW OF UNIT 3.4. -
Page 4: Important Safety Instructions
AT-iMG616RF/RF+ Series Multiservice VoIP Gateway - User Manual Important safety instructions DO NOT OPEN the product, remove screws or cover. To prevent ELECTRIC SHOCK during normal use, the plastic chassis of the product must be kept closed. This unit contains HAZARDOUS VOLTAGES and should only be opened by a trained and qualified technician. - Page 5 Be careful not to drop water or any other harmful substance onto the product. This could lead to fire or electric shock. If the unit might get in contact with liquids, unplug the power and contact your support center or sales stores. This product contains parts that are sensitive to static shock.
-
Page 6: Important Notice
AT-iMG616RF/RF+ Series Multiservice VoIP Gateway - User Manual Important notice Do not use or store the device: In direct sunlight. In a hot environment. In a low-airflow environment, such as a drawer or a closet, while the unit is turned on. Restricting airflow can damage the unit or cause a fire. -
Page 7: Contents Of The Package
Contents of the package 1: C IGURE ONTENTS OF THE PACKAGE iMG616RF/RF+ Body (Notice) The package does not contain screws. The following items are included with each AT-iMG616RF/RF+. Contact your sales representative if any items are damaged or missing. One AT-iMG616RF/RF+ One AC/DC power adapter One AT-iMG616RF/RF+ Series Multiservice VoIP Gateway User Manual One warranty card... -
Page 8: What Can The At-Img616Rf/Rf+ Do For You
AT-iMG616RF/RF+ Series Multiservice VoIP Gateway - User Manual 2.1. What can the AT-iMG616RF/RF+ do for you? The AT-iMG616RF/RF+ is Customer Premise Equipment (CPE) designed for being installed in a customer residence, it interfaces with new generation fibre networks designed to support broadband communications. -
Page 9: Product Details
Product Details 3.1. Top view of Unit 3: T IGURE OP VIEW 2: POWER/ ABLE SYSTEM INDICATIONS I Power Green light on Red light off Red light on Red light flashing System (4 flashes followed by 1 second off) Red light flashing (2 flashes followed by 1 second off) AT-iMG616RF/RF+ Series Multiservice VoIP Gateway - User Manual... - Page 10 AT-iMG616RF/RF+ Series Multiservice VoIP Gateway - User Manual 3: WAN LED ABLE INDICATIONS I Orange light off Orange light on Orange light flashing 4: V IP LED ABLE INDICATIONS WHEN THE I ON A REMOTE SERVER THE PORTS ARE ENABLED TO CALL A REMOTE NUMBER VIA A State VoIP Green light on...
-
Page 11: Front View Of Unit
3.2. Front view of unit 4: R MG616RF/RF+ IGURE EAR VIEW OF Link/Act 6: SPEED LINK/ACT LED ABLE Green light off Duplex Mode Green light on Green light off Link/act Green light on Green light flashing 3.3. Side view of unit 5: S MG616RF/RF+ IGURE... -
Page 12: 3.4. 3D View Of Unit
AT-iMG616RF/RF+ Series Multiservice VoIP Gateway - User Manual Port Power Cable Tel2/Tel1 LAN port (MDI-X) 3.4. 3D view of unit 6: 3D V MG616RF/RF+ IGURE IEW OF Function Provides the 12V DC power to this product. This product doesn’t have a power switch, you have to plug or unplug the power cable to turn the unit off. -
Page 13: Telephones And Cables
Telephones and cables 4.1. AT-iMG616 - POTS Telephone and Fax Operation Check if the dial mode is set up for tone mode (T, Tone). If not, set the switch as shown below. FIGURE 7: DIAL MODE SETTING Note, as shown in the diagram, different models of phone are likely to have different labelling on this switch. -
Page 14: Telephone Cord, Utp Cable And Tv Cable
AT-iMG616RF/RF+ Series Multiservice VoIP Gateway - User Manual 4.2. Telephone cord, UTP cable and TV cable There are 3 kinds of user connection cables: telephone cables, Unshielded Twisted Pair (UTP) cables used for data and TV coax cable for TV set. See Below. -
Page 15: Optical Fibers For Ethernet And Catv
4.3. FIGURE 10: TV CABLES To the AT-iMG-616RF/RF+ unit F-type male connector 4.4. Optical fibers for Ethernet and CATV There are 2 kinds of user connection fibers: Ethernet bi-directional fiber and CATV fiber. Ethernet fiber is a single mode fiber provided with an UPC-SC connector. CATV fiber is a single mode fiber provided with an APC-SC connector. -
Page 16: Connecting The At-Img616Rf/Rf
AT-iMG616RF/RF+ Series Multiservice VoIP Gateway - User Manual Connecting the AT-iMG616RF/RF+ 5.1. Connecting the PSTN telephone ports Connect PSTN (POTS) telephone and PSTN fax units to the TEL ports with the appropriate telephone cords. Push in the plug of the telephone cord to the TEL port until you hear a “click” and make sure it is correctly fixed by pulling the telephone cord lightly. -
Page 17: Catv Cable Connection
5.3. CATV Cable Connection To connect the TV set to the CATV port using a coax 75-ohm cables follow the procedure below: FIGURE 13: CATV CABLE CONNECTIONS 5.4. Disconnecting power supply This product doesn’t have a power switch; it automatically turns on when you connect the power cable. -
Page 18: Appendix A: Troubleshooting
AT-iMG616RF/RF+ Series Multiservice VoIP Gateway - User Manual Appendix A: Troubleshooting This Appendix describes some of the more common problems that may occur during AT- iMG616RF/RF+ installation and use. In the event of a problem, please look at the LED indications and then refer to this Appendix. -
Page 19: Fault Finding
Fault Finding Is the POWER LED on? If the power LED is off, please check if the power cable is not damaged, the power cable is correctly connected and you are using the plug with the correct power voltage. Check if the AC plug of the power cable of the product is connected correctly. This product doesn’t have a power switch. -
Page 20: Appendix B: Technical Specifications
AT-iMG616RF/RF+ Series Multiservice VoIP Gateway - User Manual Appendix B: Technical Specifications 6.1. Product Specifications AT-iMG616RF/RF+ Supported standards Interface WAN port LAN port TEL port TV port (IN) TV port (OUT) Power AC Input voltage Standard Frequency AC Input current Average power Average heat Environment condition... -
Page 21: Appendix C: Contact Information
AT-iMG616RF/RF+ Series Multiservice VoIP Gateway - User Manual Appendix C: Contact information In the event of any problem please contact your service provider or installer.
