Intel Desktop Board D865PERL Technical Product Specification

2.13 Reliability

The Mean Time Between Failures (MTBF) prediction is calculated using component and
subassembly random failure rates. The calculation is based on the Bellcore Reliability Prediction
Procedure, TR-NWT-000332, Issue 4, September 1991. The MTBF prediction is used to estimate
repair rates and spare parts requirements.
The MTBF data is calculated from predicted data at 55 ºC. The MTBF calculation for the Desktop
Board D865PERL is 101,376 hours.

2.14 Environmental

Table 46 lists the environmental specifications for the Desktop Board D865PERL.
Table 46.

Desktop Board D865PERL Environmental Specifications

Parameter
Temperature
Non-Operating
Operating
Shock
Unpackaged
Packaged
Vibration
Unpackaged
Packaged
82
Specification
-40 °C to +70 °C
0 °C to +55 °C
50 g trapezoidal waveform
Velocity change of 170 inches/second
Half sine 2 millisecond
Product Weight (pounds)
<20
21-40
41-80
81-100
5 Hz to 20 Hz: 0.01 g² Hz sloping up to 0.02 g² Hz
20 Hz to 500 Hz: 0.02 g² Hz (flat)
10 Hz to 40 Hz: 0.015 g² Hz (flat)
40 Hz to 500 Hz: 0.015 g² Hz sloping down to 0.00015 g² Hz
Free Fall (inches) Velocity Change (inches/sec)
36 167
30 152
24 136
18 118
