4.4.9 Chipset Configuration Submenu

To access this menu, select Advanced on the menu bar and then Chipset Configuration.
Maintenance
The submenu represented in Table 66 is for configuring chipset options.
Table 66.

Chipset Configuration Submenu

Feature
ISA Enable Bit
PCI Latency Timer
Burn-In Mode
Main
Advanced
PCI Configuration
Boot Configuration
Peripheral Configuration
Drive Configuration
Floppy Configuration
Event Log Configuration
Video Configuration
USB Configuration
Chipset Configuration
Fan Control Configuration
Hardware Monitoring
Options
• Disabled
• Enabled (default)
• 32 (default)
• 64
• 96
• 128
• 160
• 192
• 224
• 248
Select to display Burn-In
mode submenu
Security Power
Description
When set to Enable, a PCI-to-PCI bridge will only
recognize I/O addresses that do not alias to an ISA
range (within the bridge's assigned I/O range).
Allows you to control the time (in PCI bus clock
cycles) that an agent on the PC bus can hold the bus
when another agent has requested the bus.
Submenu used to set Burn-In mode configuration
options.
BIOS Setup Program
Boot Exit
continued
