2.11.4 Power Supply Considerations

CAUTION
The +5 V standby line for the power supply must be capable of providing adequate +5 V standby
current. Failure to do so can damage the power supply. The total amount of standby current
required depends on the wake devices supported and manufacturing options.
System integrators should refer to the power usage values listed in Table 43 when selecting a
power supply for use with the Desktop Board D865PERL.
Additional power required will depend on configurations chosen by the integrator.
The power supply must comply with the following recommendations found in the indicated
sections of the ATX form factor specification.
•
The potential relation between 3.3 VDC and +5 VDC power rails (Section 4.2)
•
The current capability of the +5 VSB line (Section 4.2.1.2)
•
All timing parameters (Section 4.2.1.3)
•
All voltage tolerances (Section 4.2.2)
For information about
The ATX form factor specification
Technical Reference
Refer to
Section 1.4, page 17
79
