Intel Desktop Board D865PERL Technical Product Specification
Table 59. Peripheral Configuration Submenu (continued)
Feature
Parallel port
Mode
Base I/O address
(This feature is present
only when Parallel Port
is set to Enabled)
Interrupt
(This feature is present
only when Parallel Port
is set to Enabled)
DMA
(This feature is present
only when Parallel Port
Mode is set to ECP)
Audio
Onboard LAN
102
Options Description
• Disabled
Configures the parallel port.
• Enabled
Auto assigns LPT1 the address 378h and the interrupt IRQ7.
• Auto (default)
An * (asterisk) displayed next to an address indicates a
conflict with another device.
• Output Only
Selects the mode for the parallel port. Not available if the
parallel port is disabled.
• Bi-directional
(default) Output Only operates in AT*-compatible mode.
• EPP
Bi-directional operates in PS/2-compatible mode.
• ECP
EPP is Extended Parallel Port mode, a high-speed
bi-directional mode.
ECP is Enhanced Capabilities Port mode, a high-speed
bi-directional mode.
• 378 (default)
Specifies the base I/O address for the parallel port.
• 278
• IRQ 5
Specifies the interrupt for the parallel port.
• IRQ 7
(default)
• 1
Specifies the DMA channel.
• 3 (default)
• Enabled
Enables or disables the onboard audio subsystem.
(default)
• Disabled
• Enabled
Enables or disables the onboard LAN device.
(default)
• Disabled
