Product Description
1.13.2.5
Standby Power (+5 V) Indicator LED
CAUTION
If AC power has been switched off and the standby power indicator is still lit, disconnect the power
cord before installing or removing any devices connected to the Desktop Board D865PERL.
Failure to do so could damage the Desktop Board D865PERL and any attached devices.
The standby power indicator LED shows that power is still present even when the computer
appears to be off. Figure 17 shows the location of the standby power indicator LED.
CR6J1
OM15902
Figure 17. Location of the Standby Power Indicator LED
49
