Audio Connectors

Figure 21 shows the location of the audio connectors.
A B
1
1
4 4
Item
A
B
C
C
1 2
9 10
Description
ATAPI-style auxiliary line input
ATAPI CD-ROM
Front panel audio
Figure 20. Audio Connectors
Technical Reference
For more information see:
Table 26
Table 27
Table 28
