Intel Desktop Board D865PERL Technical Product Specification
1.10.3.2 Front Panel Audio Connector
A 2 x 5-pin connector provides mic in and line out signals for front panel audio connectors.
For information about
The location of the connector
The signal names of the front panel audio connector
✏
NOTE
The front panel audio connector is alternately used as a jumper block for routing audio signals.
Refer to Section 2.9.1 on page 74 for more information.
1.10.3.3 ATAPI-Style CD-ROM Connector
A 1 x 4-pin connector connects an internal ATAPI CD-ROM drive to the audio mixer.
For information about
The location of the ATAPI-style CD-ROM connector
The signal names of the ATAPI-style CD-ROM connector

1.10.4 Audio Subsystem Software

Audio software and drivers are available from Intel's World Wide Web site.
For information about
Obtaining audio software and drivers
38
Refer to
Section 2.8.3, page 70
Table 28, page 64
Refer to
Figure 22, page 68
Table 27, page 64
Refer to
Section 1.2, page 16
