Save Image Dialog Box - Autodesk AUTOCAD 2006 Command Reference Manual

NOTE SAVEIMG is not available if the current rendering device does not support
scan-line images.

Save Image Dialog Box

Tools menu: Display Image
Command line: saveimg
Defines the format and position of a rendered image.
Format
Specifies the file format of the rendered image.
BMP
Saves in device-independent bitmap format. Image files are saved as either
8 or 32 bits per pixel (bpp) depending on the operating system (OS) video
color depth setting.
Offset
Defines the lower-left XY position of the image selection area. The default
is 0,0.
When you specify a nonzero offset, the number of pixels in Size can change
to reflect the remaining number of pixels to the upper-right corner of the
display area.
Options
Displays the TGA Options Dialog Box if TGA format is selected. Displays
the TIFF Options Dialog Box if TIFF format is selected.
1030 | Chapter 20
Save
