Plot Style
Click the [...] button to display the Select Plot Style Dialog Box.
Status
Click the In Use icon or the Not In Use icon.
Filter Preview
Displays the results of the filter as you define it. The filter preview shows which
layers will be displayed in the layer list in the Layer Properties Manager when
you select this filter.

Layer Filter Examples

Each example shows a layer filter definition that is set up in the Layer Filter
Properties dialog box.
Example 1
The filter named "In-use Wall layers" displays layers that meet all of the
following criteria:
Are in use
Have a name that contains the letters wall
Are on
