Details Area
Lists details of completed plot and publish jobs. For each job and sheet, the
details area provides the following information:
Job and sheet names
Path for job plotted to file (if applicable)
Job completion status, along with whether errors or warnings occurred
Date and time started and completed
Total sheets in the job and total sheets plotted
Number of errors and warnings that occurred
Detailed information about errors or warning that occurred
Plot and Publish Status Bar Icon Shortcut
Menu
When background plotting is enabled, provides options for cancelling the
sheet that is currently being plotted, cancelling the entire plot or publish job,
viewing the Plot and Publish Details Dialog Box, and viewing the most recently
created Design Web Format (DWF
publish icons in the tray on the right side of the status bar. These icons are
described in the following table.
Cancel Entire Job
Cancels the entire plot or publish job.
Cancel Sheet
Cancels the sheet that is currently being plotted.
1268 | Chapter 23
This animated icon indicates that a plot or publish job is currently being
processed in the background
A plotting details report is available. No errors and warnings occurred.
A plotting details report is available. Errors and warnings occurred.
™
) file. Right-click any of the plot and
