By ACI
Displays the Attach by AutoCAD Color Index Dialog Box, in which you can
select an ACI to attach a material to.
By Layer
Displays the Attach by Layer Dialog Box, in which you can select a layer to
attach a material to.
Detach
Closes the dialog box temporarily so that you can select an object and
detach the material from it.
Duplicate
Duplicates a material and displays one of four dialog boxes, depending on
which material type is selected in the list under the New button: Standard,
Marble, Granite, or Wood. Use the dialog box to name the new material
and define attributes.
Materials
Lists the available materials. Use MATLIB to add other materials. The default
for objects with no other material attached is GLOBAL.
Materials Library
Displays the Materials Library dialog box, in which you select a material.
See MATLIB.
Modify
Displays one of four dialog boxes, depending on which material type is
selected in the list under the New button: Standard, Marble, Granite, or
Wood. Use the dialog box to edit an existing material.
New
Displays one of four dialog boxes, depending on which material type is
selected in the list under the New button:
"New or Modify Standard Material Dialog Box" on page 991
"New or Modify Granite Material Dialog Box" on page 997
"New or Modify Marble Material Dialog Box" on page 999
"New or Modify Wood Material Dialog Box" on page 1001
990 | Chapter 19
