Server Board Components; Figure 12. System Power Led Back Panel - Intel SR2612UR - Server System - 0 MB RAM Service Manual

Item
A. Standby Power
OK LED (+3.3V)
B. System Status LED
C. System Status LED
D. System Identification
LED
E. Power Switch

Server Board Components

This section helps you identify the components and connectors on the server board.
18
Function Color
Green
Green
Amber
Blue
N/A

Figure 12. System Power LED Back Panel

State
Off AC Power Off
On AC power on or DC power on
Solid On System booted and ready
Blink Degraded
Blink Non-critical
Solid On Critical, non-recoverable
On Identify active through command
Off No Identification
N/A N/A
®
Intel Server System SR2612UR Service Guide
Description
