I/O board illustration

The following illustration shows the location of the switches, jumpers, and connectors on the I/O
board.
S
R
Q
P
O
I
N

Switches

Table 2 describes the function of each switch on the Config DIP switch block (S6H1).
Table 2. Config DIP Switch S6H1
Switch
number Default value
1 Off
2 Off
3 Off
4 Off
5 Off
10
B C
A D
H
K
M
L
Switch
description
Not used
Password clear
CMOS clear
Reserved
BMC force update
Intel® Server Compute Blade SBX44: Installation and User's Guide
E
J
F
G
A NMI Error LED
B BMC Error LED
Temp Error LED
C
D I/O Board Error LED
Light Path Diagnostics* LED
E
F Processor Board Error LED
Board Error LED
G
H Secondary IDE Error LED
I Primary IDE Error LED
J Light Path Diagnostics* Button
K Secondary IDE Connector
Config DIP Switch
L
Primary IDE Connector
M
N Battery
O
BIOS Code Page Jumper
P I/O Expansion Option 2
Q
I/O Expansion Option 1
R
Flex Cable Connectors
S
SCSI Expansion Connector
