Features and specifications

The following table provides a summary of the features and specifications of your blade server.
NOTE
Power, cooling, removable-media drives, external ports, and advanced system management
are provided by the system chassis.
Microprocessor:
Supports up to 4 microprocessors
®
Intel
Xeon
2.0 GHz or faster
1 MB, 2MB or 4 MB ECC L2
cache
Memory:
Eight double data rate (DDR)
266 PC1600 sockets
operating at 200 MHz
Minimum: 512 MB
Maximum: 16 GB
Type: 2-way interleaved, DDR,
PC2100, ECC SDRAM
registered x4 (Chipkill) DIMMs
only
NOTE
PC2100 DIMMs are
backward-compatible
and can function in the
PC1600 sockets
Supports 256-MB, 512-MB,
1-GB and 2-GB dual inline
memory modules (DIMMs)
Drives:
Support for up to two internal
IDE 2.5-inch hard disk drives
Support for up to two Ultra320
SCSI hot-swap hard disk
drives available in an optional
SCSI storage expansion unit
Expansion:
(2) IO expansion card
connectors for auxiliary fabric
attach point (PCI-X internal
interface and SERDES
external interface)
4
Size:
Height: 24.5 cm (9.7 inches)
Depth: 44.6 cm (17.6 inches)
Width: 5.9 cm (2.32 inches)
Maximum weight: 5.4 kg (12
lb)
Integrated functions:
Four Gigabit Ethernet
controllers
ATI* Radeon 7000 video
controller
Light Path Diagnostics*
Local service processor
IDE hard disk drive controller
RS-485 interface for
communication with system
chassis management
module
Sahalee-based BMC
management features
USB buses for
communication with
keyboard, mouse, diskette
drive, and CD-ROM drive
SOL management interface
Predictive Failure Analysis
(PFA) alerts:
Microprocessor
Memory
Hard disk drives
BIOS:
2MB flash with rolling BIOS
support and 4 MB diagnostic
space (8 MB total)
Intel® Server Compute Blade SBX44: Installation and User's Guide
Environment:
Air temperature:
— Blade server on: 10° to
35°C (50° to 95°F).
Altitude: 0 to 914 m
(2998.69 ft)
— Blade server on: 10° to
32°C (50° to 95°F).
Altitude: 914 m to 2134 m
(2998.69 ft to 7000 ft)
— Blade server off: -40° to
60°C (-40° to 140° F)
Humidity:
— Blade server on: 8% to
80%
— Blade server off: 5% to
80%
Electrical input:
Input voltage: 12 V dc
Power:
Dual redundant 12V DV (400W
max)
Thermal:
Enterprise: 40 CFU, 35°C,
1500 m
Telco: 40 CFU, 40°C, 1800 m
