Disconnect the I/O board power cable (E) from its connector on the CPU board.
A
12. Slide the CPU board out of the blade chassis by sliding the CPU board rearward (A) and then
lifting upward (B).
B
Service replaceable units
B
D
C
E
TP00463
A
TP00465
59
