7. Remove any IDE drives or daughter cards if installed. Loosen the four screws (A) on each of the
IDE drive trays. Remove the IDE drive tray (B).
NOTE
If an I/O expansion card is installed in place of an IDE drive, then loosen the four screws
on the I/O expansion card tray.
8. Slide I/O board out of I/O board assembly. Note the position of the five guide hooks and two
guide pins on the I/O board assembly.
68
B
Intel® Server Compute Blade SBX44: Installation and User's Guide
A
TP00461
A
A
TP00458
