3. Align the four metal tabs (A) on the bezel assembly with the four slots (B) on the front of the
blade chassis. Insert the metal clips into the underside of the slots, and then rotate the bezel
assembly up until it clicks into place.
NOTE
It may be easiest to perform this step by placing the blade chassis over the edge of a flat
surface. Be sure to support the bezel assembly while doing so.
A
C
Installing options
B
D
E
TP00455
43
