⇒ The stacker will be fixed in a position tilting forward.
HINT
ATTENTION
<Switching back to the horizontal setting
1. Slide the stacker out towards you.
2. Push down the inner part of the stacker.
⇒ The stacker goes back into its horizontal position.
3. Move your hands away from the stacker slowly.
• When set to "Bottom edge" position, the stacker does not move up or
down and becomes immovable even during scanning operation.
• In this position, the stacker's maximum load will be 200 sheets.
• If the pages do not stack well, use the Document Smoother. (See next
section.)
When you align the documents from the leading edge (by tilting forward
setting of stacker), the documents must meet the following conditions:
(
Length
) ÷ ( ) <
Width 1.5
2.7 Setting up the Stacker
