Fujitsu 5900C - fi - Document Scanner Operator's Manual page 198

Setting Example 1:
Specified area = Right, Selected mode = Non-detection area, Start = 50mm, End = 200mm
Setting Example 2:
Specified area = Middle, Selected mode = Detection area, Start = 50mm, End = 200mm
HINT
178
8.4 Multifeed Detection
35 35
60
35 35
60
When you want to detect overlapping, be sure that paper documents are not
clinging to each other. Those clinging documents (glued or with static cling)
may cause a lower multifeed-detection ratio.
35
50
200
Unit: mm
60
35
50
200
Unit: mm
60
