3.
Adjust the Offset/Scan scale as necessary.
Offset setting
Target:
Horizontal:
Vertical:
Scan scale setting
Target:
Vertical:
174
8.3 Offset/Scan scale
Select ADF front or ADF back as target.
Adjusts the horizontal Offset.
Setting range -2mm to +3mm, in steps of 0.5mm.
Adjusts the vertical Offset.
Setting range -2mm to +3mm, in steps of 0.5mm.
Select ADF front or ADF back as target.
Adjusts the vertical (document length) Scan scale.
Setting range -6.3% to +6.3%, in steps of 0.1%.
