V
V
Vehicles with front and rear
foglamps
(Ring B)
They
sidelamps,
beams or main beams
are switched on.
For a vehicle equipped with rear
foglamps:
- 1st notch forwards: switches on
rear foglamps.
- 1st notch rearwards: switches off
rear foglamps.
66
For a vehicle equipped with front
and rear foglamps:
- 1st notch forwards: switches on
front foglamps.
- 2nd notch forwards: switches on
rear foglamps.
- 1st notch rearwards: switches off
rear foglamps.
- 2nd notch rearwards: switches off
front foglamps.
Note:
The rear foglamps must only be
used when visibility is severely re-
duced (fog, snow).
operate
when
dipped
In conditions of poor visibility,
if the ambient brightness does
not trigger the automatic light-
ing, it is up to you to switch on
your dipped beams manually,
as well as your foglamps.
V I S I B I L I T Y

HEADLAMP ADJUSTMENT

You are advised to adjust the aim of
the headlamps in accordance with
vehicle load.
In the dashboard on the right hand
side of the steering column.
0.
1 or 2 occupants in the front
seats.
-.
3 occupants.
1.
5 occupants.
-.
Intermediate position.
2.
5 occupants + maximum au-
thorised load.
-.
Intermediate position.
3.
Driver + maximum authorised
load.
Note: vehicles equipped with Xenon
headlamps have automatic head-
lamp adjustment.
