Introducing Cisco Small Business Analog Telephone Adapters
ATA Software Features
Cisco Small Business ATA Administration Guide
Feature
Modem and Fax
Pass-Through
Adaptive Jitter
Buffer
International Caller
ID Delivery
Description
•
Modem pass-through mode can be triggered only by
predialing the number set in the
(Set in the Regional tab.)
•
FAX pass-through mode is triggered by a CED/CNG tone or
an NSE event.
•
Echo canceller is automatically disabled for Modem pass-
through mode.
•
Echo canceller is disabled for FAX pass-through if the
parameter FAX Disable ECAN
for that line (in that case FAX pass-through is the same as
Modem pass-through).
•
Call waiting and silence suppression is automatically
disabled for both FAX and Modem pass-through. In addition,
out-of-band DTMF Tx is disabled during modem or fax pass-
through.
The ATA device can buffer incoming voice packets to
minimize out-of-order packet arrival. This process is
known as jitter buffering. The jitter buffer size proactively
adjusts or adapts in size, depending on changing network
conditions.
The ATA device has a Network Jitter Level control setting
for each line of service. The jitter level determines how
aggressively the ATA device tries to shrink the jitter buffer
over time to achieve a lower overall delay. If the jitter level
is higher, it shrinks more gradually. If jitter level is lower, it
shrinks more quickly.
Adaptive Jitter Buffer is configured in the Line and PSTN
Line tabs. See "ATA Voice Field Reference," on
page 115.
In addition to support of the Bellcore (FSK) and Swedish/
Danish (DTMF) methods of Caller ID (CID) delivery, ATAs
provide a large subset of ETSI-compliant methods to
support international CID equipment. International CID is
configured in the Line and PSTN Line tabs. See
Voice Field Reference," on page
Modem Line Toggle Code.
(Line 1 or 2 tab) is set to "yes"
"ATA
115.
