Gateway Accounts Section (Spa3102); Voip Fallback To Pstn Section (Spa3102 And Spa8800) - Cisco SPA2102-AN - Single Port Router Administration Manual

ATA Voice Field Reference
Line page
Cisco Small Business ATA Administration Guide

Gateway Accounts section (SPA3102)

Gateway1/2/3/4
GW1/2/3/4 NAT
Mapping Enable
GW1/2/3/4 Auth ID
GW1/2/3/4
Password
Voice tab > Line page >

VoIP Fallback to PSTN section (SPA3102 and SPA8800)

On the SPA8800, these settings are configured on the Phone pages only.
Auto PSTN Fallback If enabled, the ATA device automatically routes all calls to
The first of 4 gateways that can be specified to be used in
the <Dial Plan> to facilitate call routing specification (that
overrides the given proxy information). This gateway is
represented by gw1 in the <Dial Plan>. For example, the
rule 1408xxxxxxx<:@gw1> can be added to the dial plan
such that when the user dials 1408+7digits, the call will be
routed to Gateway 1. Without the <:@gw1> syntax, all calls
are routed to the given proxy by default (except IP dialing).
The default is blank.
If enabled, the ATA device uses NAT mapping when
contacting Gateway 1.
The default is no.
This value is the authentication user-id to be used by the
SPA to authenticate itself to Gateway 1.
The default is blank.
This value is the password to be used by the SPA to
authenticate itself to Gateway 1.
The default is blank.
the PSTN gateway when the Line 1 proxy is down
(registration failure or network link down).
The default is yes.
B
180
