Streaming Audio Server (Sas) Section - Cisco SPA2102-AN - Single Port Router Administration Manual

ATA Voice Field Reference
Line page
Cisco Small Business ATA Administration Guide
Voice tab > Line page >

Streaming Audio Server (SAS) section

On the SPA8800, these settings are configured on the Phone pages only.
SAS Enable
SAS DLG Refresh
Intvl
To enable the use of the line as a streaming audio source,
select yes. Otherwise, select no. If enabled, the line cannot
be used for outgoing calls. Instead, it auto-answers
incoming calls and streams audio RTP packets to the caller.
The default is no.
If this value is not zero, it is the interval at which the
streaming audio server sends out session refresh (SIP re-
INVITE) messages to determine whether the connection to
the caller is still active. If the caller does not respond to the
refresh message, the ATA device ends this call with a SIP
BYE message. The range is 0 to 255 seconds (0 means that
the session refresh is disabled).
The default is 30.
B
162
