Loading paper
4
Open the control panel cover to access layer 2.
5
Press any paper movement button (Micro , Micro , LineFeed) to align the horizontal lines located on the platen
with the Top‑Of‑Form you want.
Note: If you press and hold a paper movement button, the paper will advance in micro movements and then go
into continuous feed mode.
6
Press Set TOF to set and save your Top‑Of‑Form.
7
Close the control panel cover.
8
Press Start/Stop to put the printer online.
Setting Top‑Of‑Form in a macro
Each macro has a separate Top‑Of‑Form setting. To set Top‑Of‑Form in a macro, you must first select that macro.
1
Open the control panel cover to access layer 2.
2
Press Macro to select the macro you want to use.
Note: The procedure for setting Top‑Of‑Form depends on the paper and print mode you are using. For help, see
one of the following sections in this chapter:
•
"Setting Top‑Of‑Form for continuous forms in push mode" on page 40
•
"Setting Top‑Of‑Form for continuous forms in pull mode" on page 41
•
"Setting Top‑Of‑Form for a cut form or an envelope" on page 41
1 2 3 4
Power
Set TOF LineFeed Macro
Micro Micro Setup
10 20
Pitch
12 24
15
17
Lock
42
