LAYER Page
2
1
Element select buttons
Select the Element you wish to edit.
2
Element On/Off switches
The [AWM1] – [AWM4] buttons indicate the Elements which make up the selected
Voice, and the [VA] button indicates the VA tone generator (the [VA] button is grayed
out when you are editing an AWM Voice). You can mute any of the Elements by simply
pressing the corresponding button. Pressing the button again cancels the mute. Muting
all other Elements except for the one you are editing lets you clearly hear that single
Element for ease in editing. Note that when some Elements are muted, playing the
keyboard in certain key areas or with certain velocities may result in no sound.
3
Display switch buttons
The LAYER Page contains three pages. The
them.
LAYER Page 1
1
1
VOICE/ELEMENT
Indicates the Voice/Element currently being edited. For example, the screen above
shows that Element 1 of Accordion 1 is being edited.
You can also call up another Element from another Voice and replace the currently
selected Element with it. Pressing the VOICE or ELEMENT button in the display
calls up the Voice or Element menu, from which you can select the desired Voice/
Element.
buttons are used to switch among
2 3 4
1
3
These buttons
switch the
display.
