Yamaha ELS-02 Owner's Manual

Checking the included items
Remove all parts from the package and make sure you have
all of the items.
• Bench board 1
• Legs 4
• Foot rest 1
• Bolts 4
• Washers 4
• Screws 4
• Wrench* 1
*Wrench is attached on the backside of bench board.
Have a Phillips-head (+) screwdriver of the appropriate size
ready.
Bench assembly
1
Turn the bench board over and install two
legs for the front side.
Tighten the bolts using the included wrench (as
shown).
CAUTION
Make sure to put washers between the bolts and the
bench board. Make sure to properly tighten all bolts so
that there is no gap between the bolts and the washers.
If the bolts are not properly tightened, accident or injury
may occur.
R
Logo is written on back
Bench for ELS-02/ELS-02C Owner's Manual
Washer
Bolt
L
2
Install the foot rest to the legs with the
included four screws, using a screwdriver.
3
Install the two legs for the back side.
After completing the assembly, be sure to read the
"PRECAUTIONS" section of the Owner's Manual of
ELS-02/ELS-02C.
– 1 –
Foot rest
