Installation instructions, only for experts
5.2. Connection diagram for 230 V
Fig. 7: Connection area for 230 V
4
Mains connection cable 230 V / 50 Hz max. 16 A
5 Infrared heater max. 3.5 kW
6
Remote start (230 V / 50 Hz)
230V/50Hz
max.16A
230V/50Hz
max.3,5kW
4 5
p. 16/32
230 VAC
6
