reception process is finished. In some locations, RCC reception may take a
couple of days to receive the signal.
6. Display Console Features
6.1 Quick Set Mode
Note: The console has five keys for easy operation: HISTORY/- key,
ALARM key, SET/MODE key, CHANNEL/+ key and SNOOZE key
Note: To exit the Quick SET Mode at any time, press the SNOOZE
button of the display console.
While in Normal Mode, press (do not hold) the SET/MODE key repeatedly
to enter into below 4 modes:
 once for date and year.
 twice times for outdoor temperature and dew point.
 three times for pressure absolute (ABS) and relative(REL).
 four times for 72h or 24h graph record
1. Date and Year. Press the HISTORY/- key to toggle between year and
date.
2. Temperature and Dew point. Press the HISTORY/- key to toggle
between temperature and dew point for outdoor.
3. Absolute Pressure and Relative Pressure. Press the CHANNEL/+ or
HISTORY/- key to toggle between absolute pressure and relative
pressure.
4. 72h or 24h Graph Record. Press the CHANNEL/+ or HISTORY/- key
to toggle between the last -72 hours or -24 hours record time. Each bar
represents the corresponding data and time for pressure, temperature
or humidity.( default is -72 hours),as shown in Figure 6.
Note: The graph displays hours on the horizontal or x-axis (the most
recent data to the right of the graph). For example, 0h is the current data
Figure 6
