DEXXO COMPACT io
– The structures of the garage (walls, lintel, partitions, ceiling, etc.) enable the motorisation to be mounted securely. Reinforce
these if necessary.
– the door can be correctly opened and closed using a force of less than 150 N.
DANGER
It is dangerous to perform any operation on the door springs (the door may fall).
1.3.3 Specifications of the door to be motorised
After installation, ensure that the parts of the door do not encroach onto the pavement or public thoroughfare.
WARNING
Gate
If the garage door is fitted with a wicket door, the door must be equipped with a system that prevents it from moving
when the wicket door is not in the safety position.
1.4 Risk prevention
WARNING
Ensure that any danger zones (crushing, cutting, trapping) between the driven section and the surrounding fixed sec-
tions created by the opening of the driven section are prevented, or indicated on the installation.
Permanently affix the crushing warning labels near any fixed control devices or so that they are clearly visible.
1.4.1 Risk prevention – motorisation for residential sectional / up-and-over garage door
Zone 4
Zone 5
Zone 3
Zone 1
Zone 4
©
Copyright
2024 SOMFY ACTIVITES SA. All rights reserved.
Zone 2
7
