3 I
NSTALLATION
3.1 Recommendations
CAUTION
if the garage door is the sole means of access to the garage, install an external back release device (ref. 9012961 or ref.
9012962).
The position in which the motorisation will be fitted must allow for safe and easy manual release of the product.
3.2 Installation height
Measure the distance "D" between the highest point of the door and the ceiling.
• If "D" is between 35 and 200 mm, secure the assembly directly to the ceiling.
• If "D" is greater than 200mm, secure the assembly so that the height "H" is between 10 and 245 mm.
16
DEXXO COMPACT io
35 < D < 200
D > 200
D
10 < H < 245
©
