6.2 Description of the various peripherals
6.2.1 Photoelectric cells with auto-test
WARNING
Installing this type of cell is mandatory in case of operation in remote control mode or with automatic closing.
BATT
STOP
CELL
10 9
8
7
1.
Wire the cells.
NOTICE
If the SET indicator light is off, briefly press a button to exit low consumption mode.
2.
Program P3=2.
CAUTION
When aligning the cells during their installation, the drive must not be in low consumption mode.
6.2.2 Orange light
BATT
STOP
CELL
10 9
8
7
If Sequential operating mode + closing time-delay is activated via TaHoma Pro, the orange light will flash for 2 s before the movement
starts.
30
ANT
FLASH
6
5
4
3
2
1
ANT
FLASH
6
5
4
3
2
1
DEXXO COMPACT io
©
