SOMFY DEXXO COMPACT io Manual page 13

DEXXO COMPACT io
Off
Permanently lit
No. Designation
1 PROG indicator light
2 PROG button
3 + button
4 - button
5 SET button
6 SET indicator light
7 Built-in lighting
8 Terminal block
©
Copyright 2024 SOMFY ACTIVITES SA. All rights reserved.
Comments
: Radio reception
During parameter setting, the number of flashes indicates the parameter value.
: Radio control point memorisation confirmed
: Awaiting radio control point memorisation
Press for 0.5 s: when programming the radio control points, selects the function to
be memorised
Press for 2 s: opens the memory for programming the radio control points
Press for 7 s: erases the radio control points
Before auto-programming, hold down the button to open the door
Interrupts auto-programming
During parameter setting, modifies the value of a parameter
After auto-programming, a short press opens the door, or stops it if it is moving
Before auto-programming, hold down the button to close the door
Interrupts auto-programming
During parameter setting, modifies the value of a parameter
After auto-programming, a short press closes the door, or stops it if it is moving
Press for 0.5 s: enters and exits the parameter setting menu
During parameter setting, selects the parameters
Press for 2 s: triggers auto-programming
Press for 7 s: clears auto-programming and parameters
Interrupts auto-programming
: The first time the unit is powered on, programming has not been carried out
During parameter setting, the number of flashes corresponds to the selected para-
meter.
: Programming in progress
: Programming complete
: Electronics fault (motor thermal cut-out, etc.)
: Drive in low consumption mode
230V power supply
Photoelectric cells
Orange light
Wired control point
Gate contact
9.6V battery or solar kit
Remote antenna
Slow flashing
Rapid flashing
Very rapid flashing
13
