Ruijie Reyee RG-APF1250 Configuration Manual
  1. Manuals
  2. Brands
  3. Ruijie Manuals
  4. Wireless Access Point
  5. Reyee RG-APF1250
  6. Configuration manual
Ruijie Reyee RG-APF1250 Configuration Manual

Ruijie Reyee RG-APF1250 Configuration Manual

Reyeeos 2.290
Hide thumbs

Advertisement

Quick Links

Download this manual
Ruijie Reyee RG-APF1250
Access Point
ReyeeOS 2.290
Configuration Guide
Document Version: V1.0
Date: 2024-05-14
Copyright © 2024 Ruijie Networks

Advertisement

loading
Need help?

Need help?

Do you have a question about the Reyee RG-APF1250 and is the answer not in the manual?

Questions and answers

Related Manuals for Ruijie Reyee RG-APF1250

Summary of Contents for Ruijie Reyee RG-APF1250

  • Page 1 Ruijie Reyee RG-APF1250 Access Point ReyeeOS 2.290 Configuration Guide Document Version: V1.0 Date: 2024-05-14 Copyright © 2024 Ruijie Networks...
  • Page 2 Ruijie Networks reserves the right to modify the content of the document without any notice or prompt. This manual is designed merely as a user guide. Ruijie Networks has tried its best to ensure the accuracy and reliability of the content when compiling this manual, but it does not guarantee that the content of the manual is completely free of errors or omissions, and all the information in this manual does not constitute any explicit or implicit warranties.
  • Page 3 Intended Audience This document is intended for:  Network engineers  Technical support and servicing engineers  Network administrators Technical Support  Official Website of Ruijie Reyee: https://reyee.ruijie.com  Technical Support Website: https://reyee.ruijie.com/en-global/support  Case Portal: https://www.ruijienetworks.com/support/caseportal  Community: https://community.ruijienetworks.com ...
  • Page 4 Specification An alert that contains a description of product or version support. Notes This manual introduces the product model, port type and CLI for your reference. In case of any discrepancy or inconsistency between the manual and the actual version, the actual version prevails.
  • Page 5 Contents Preface ..............................I 1 Fast Internet Access .......................... 1 1.1 Configuration Environment Requirements ................1 1.1.1 PC ..........................1 1.2 Logging In to the Web Interface ....................1 1.2.1 Connecting to the Device ....................1 1.2.2 Configuring the IP Address of the Management Client ..........1 1.2.3 Logging in to the Web Interface ..................
  • Page 6 2.4.2 Configuration Steps ..................... 13 2.5 Checking Wireless Clients ....................... 14 2.6 Configuring the Wi-Fi Band ...................... 15 2.7 Configuring Band Steering....................... 15 2.8 Configuring Wi-Fi 6 ........................16 2.9 Configuring Wi-Fi 7 ........................17 2.10 Enable Layer-3 Roaming ....................... 18 2.11 Configuring Client Isolation ....................
  • Page 7 2.14.10 Configuring the Access Threshold ................27 2.14.11 Configuring the Response RSSI Threshold ............. 27 2.14.12 Configuring WIO ...................... 28 2.14.13 Configuring K/V Roaming Optimization ..............29 2.15 Configuring Healthy Mode ..................... 30 2.16 Configuring XPress ........................ 31 2.17 Configuring Wireless Schedule ..................... 31 3 Network Settings ..........................
  • Page 8 3.10.3 Configuration Steps ....................41 4 System Settings ..........................44 4.1 Setting the Login Password ..................... 44 4.2 Setting the Session Timeout Duration ..................44 4.3 Setting and Displaying System Time ..................45 4.4 Configuring Reboot ........................46 4.4.1 Rebooting the Current Device ..................46 4.4.2 Rebooting All Devices on the Network ................
  • Page 9 6 FAQs ..............................58 6.1 Fail to Log In to the Web Interface ..................58 6.2 Restore Factory Settings ......................58 6.3 Forgot Password ........................58...
  • Page 10 Wireless connection On a mobile phone or laptop, search for a wireless network whose Wi-Fi name is @Ruijie-bXXXX. (XXXX is the last four digits of the MAC address of the device). In this mode, you do not need to set the IP address of the management client, and can skip the steps in 1.2.2 Configuring the IP Address of the Management Client.
  • Page 11 Configuration Guide Fast Internet Access  The IP address of the management client cannot be set to 10.44.77.253, because this IP address is reserved by the device. If the management client uses this IP address, it cannot access the device. 1.2.3 Logging in to the Web Interface (1) Enter the IP address (10.44.77.254 by default) of the device in the address bar of the browser to open the...
  • Page 12 Configuration Guide Fast Internet Access Work Modes The device works in AP mode. The device performs L2 forwarding and does not support the DHCP function. In AP mode, the device often networks with devices supporting the routing function. IP addresses of downlink wireless clients of the device are assigned and managed by its uplink device (supporting the DHCP function) in a unified manner, and the device only transparently transmits data.
  • Page 13 Configuration Guide Fast Internet Access (3) Country/Region: The Wi-Fi channel may vary from country to country. To ensure that a client searches for a Wi-Fi network successfully, you are advised to select the actual country or region. (4) Time Zone: Set the system time. The network time server is enabled by default to provide the time service. You are advised to select the actual time zone.
  • Page 14 Configuration Guide Fast Internet Access Web Interface To facilitate flexible device management, the web interface displays different system configuration menus in different work modes. For details about the device work mode, see Switching Work Mode. For RG-APF1250, see 1.5.1 Single-mode Management Page.
  • Page 15 Configuration Guide Fast Internet Access 2. Standalone Management  If the device is in self-organizing network mode, click the name of the currently logged-in device or click Manage of a specified device in the APs by choosing WLAN > APs to configure and manage the device. ...
  • Page 16 Configuration Guide Fast Internet Access 1.5.2 Dual-Mode Management Page 1. Management Mode The self-organizing network is enabled by default. You can disable it manually. If the self-organizing network is disabled, the device works in the local device mode. If the self-organizing network is enabled, the device can work in the SON mode and the local device mode. You can switch between the two modes on the web interface.
  • Page 17 Configuration Guide Fast Internet Access Local Device mode web interface: 2. Switching the Management Mode Click the current management mode in the navigation bar, and select the mode in the drop-down box to switch the work mode of the device.
  • Page 18 Configuration Guide Wi-Fi Network Settings Wi-Fi Network Settings Note Wi-Fi network settings cover the Wi-Fi settings of the currently logged in device and the management of all wireless devices on the network. If the self-organizing network feature is enabled, the Wi-Fi network settings will be synchronized to all wireless devices on the network.
  • Page 19 Configuration Guide Wi-Fi Network Settings (3) Click the group name on the left pane to view all devices in the group. A device can only belong to one group. By default, all devices belong to the default group. Select an entry in the list and click Change Group to move the target device to a specified group.
  • Page 20 Configuration Guide Wi-Fi Network Settings Table 2-1 Wireless Network Parameters Parameter Description SSID The name displayed when a wireless client searches for a wireless network. The SSID encoding standard is set to "UTF-8" by default when Chinese characters are SSID Encoding included in the SSID.
  • Page 21 Configuration Guide Wi-Fi Network Settings Parameter Description Wireless mode, including 802.11be (Wi-Fi 7), 802.11ax (Wi-Fi 6), and compatible mode 802.11be (Wi-Fi 7): This parameter takes effect only on APs that support the IEEE 802.11be protocol. In addition, the connected terminals must support the IEEE 802.11be protocol to experience the high-speed Internet access experience brought by Wi-Fi 7.
  • Page 22 Configuration Guide Wi-Fi Network Settings Internet without a password. The Wi-Fi password must be a string of 8 to 16 characters, which can contain letters, digits, and special characters (<=>[]!@#$*()). Caution After the configuration is saved, all clients will be disconnected from the Wi-Fi. You need to enter the new password to connect to the Wi-Fi network.
  • Page 23 Configuration Guide Wi-Fi Network Settings Caution After the configuration is saved, you have to manually enter the SSID and Wi-Fi password before connecting any device to the Wi-Fi network. Exercise caution when performing this operation. Checking Wireless Clients Choose Clients > Online Clients > Wireless.
  • Page 24 Configuration Guide Wi-Fi Network Settings Configuring the Wi-Fi Band (1) Go to the configuration page:  Method 1: Choose WLAN > Wi-Fi > Wi-Fi Settings. Select the target Wi-Fi.  Method 2: Choose WLAN > Wi-Fi > Wi-Fi List. Select the target Wi-Fi in the list and click Edit in the action column.
  • Page 25 Configuration Guide Wi-Fi Network Settings column. (2) Click Expand, turn on Band Steering in the expanded settings, and click Save. After the function is enabled, the client supporting 5 GHz selects the 5G Wi-Fi network preferentially. Configuring Wi-Fi 6 Caution The function takes effect only on APs supporting the IEEE 802.11ax protocol.
  • Page 26 Configuration Guide Wi-Fi Network Settings Configuring Wi-Fi 7 Caution This configuration takes effect only on APs that support the IEEE 802.11be protocol. In addition, the connected clients must support the IEEE 802.11be protocol to experience the high-speed Internet access brought by Wi- Fi 7.
  • Page 27 Configuration Guide Wi-Fi Network Settings 2.10 Enable Layer-3 Roaming (1) Go to the configuration page:  Method 1: Choose WLAN > Wi-Fi > Wi-Fi Settings. Select the target Wi-Fi.  Method 2: Choose WLAN > Wi-Fi > Wi-Fi List. Select the target Wi-Fi in the list and click Edit in the action column.
  • Page 28 Configuration Guide Wi-Fi Network Settings 2.11 Configuring Client Isolation (1) Go to the configuration page:  Method 1: Choose WLAN > Wi-Fi > Wi-Fi Settings. Select the target Wi-Fi.  Method 2: Choose WLAN > Wi-Fi > Wi-Fi List. Select the target Wi-Fi in the list and click Edit in the action column.
  • Page 29 Configuration Guide Wi-Fi Network Settings 2.13 Configuring Wi-Fi Blocklist/Allowlist 2.13.1 Overview You can configure a global Wi-Fi blocklist/allowlist. Wi-Fi blocklist: Clients in the Wi-Fi blocklist are prevented from accessing the Internet. Clients that are not added to the Wi-Fi blocklist are free to access the Internet. Wi-Fi allowlist: Only clients in the Wi-Fi allowlist can access the Internet.
  • Page 30 Configuration Guide Wi-Fi Network Settings 2.14 Optimizing Wi-Fi Network 2.14.1 Overview The device detects the surrounding wireless environment and selects the appropriate configuration upon power- on. However, network stalling caused by wireless environment changes cannot be avoided. You can optimize the network with one single click, analyze the wireless environment around the access point and select appropriate parameters.
  • Page 31 Configuration Guide Wi-Fi Network Settings 2.14.3 Optimizing the Radio Channel  Primary device: Choose WLAN > Radio Frequency  Secondary device: Choose WLAN > APs. Select the target device in the device list and click Manage > WLAN > Radio Frequency. Choose the best channel identified by a Wi-Fi test tool.
  • Page 32 Configuration Guide Wi-Fi Network Settings 2.14.4 Optimizing the Channel Width Choose WLAN > Radio Frequency. A network with a lower channel width is more stable, while a network with a higher channel width is susceptible to interference. If the interference is severe, choose a lower channel width to avoid network stalling to a certain extent.
  • Page 33 Configuration Guide Wi-Fi Network Settings 2.14.6 Configuring the Multicast Rate Choose WLAN > Radio Frequency. If the multicast rate is too high, the packet loss rate of multicast packets may increase. If the multicast rate is too low, the radio interface may become busy. When network stalling is serious, you are advised to configure a high multicast rate.
  • Page 34 Configuration Guide Wi-Fi Network Settings You can lower the threshold if there is requirement for bandwidth per client. You are advised to keep the default settings unless there are special cases. After adjusting the configuration, click Save. Note The Client Count Limit refers to the maximum number of clients that can be connected to a single access point.
  • Page 35 Configuration Guide Wi-Fi Network Settings Caution In the self-organizing network mode, the disconnection threshold settings will be synchronized to all devices in the network. 2.14.9 Configuring the Roaming Sensitivity  Primary device: Choose WLAN > Radio Frequency.  Secondary device: Choose WLAN > APs. Select the target device in the device list and click Manage > WLAN >...
  • Page 36 Configuration Guide Wi-Fi Network Settings 2.14.10 Configuring the Access Threshold  Primary device: Choose WLAN > Radio Frequency.  Secondary device: Choose WLAN > APs. Select the target device in the device list and click Manage > WLAN > Radio Frequency When the wireless signal of the end user is lower than the access threshold set on the device, the client cannot detect the wireless signal of the device.
  • Page 37 Configuration Guide Wi-Fi Network Settings WLAN > Radio Frequency. When the wireless signal of the end user is lower than the response RSSI threshold configured on the device, the client cannot detect the wireless signal of the device. The smaller the response RSSI threshold is configured, the less the environmental factors interfere with the AP.
  • Page 38 Configuration Guide Wi-Fi Network Settings 2.14.13 Configuring K/V Roaming Optimization Go to the configuration page: Choose Network > WIO > 802.11k/v Roaming Optimization. Select the optimization mode, and then click Enable. The Wi-Fi roaming is further optimized using the 802.11k/v protocol.
  • Page 39 Configuration Guide Wi-Fi Network Settings Table 2-3 Optimization Mode Parameters Parameter Description Performance- Maximum negotiation speed is guaranteed, but connection stability may be compromised. prior Roaming-prior Connection stability is guaranteed, but maximum negotiation speed may be reduced. 2.15 Configuring Healthy Mode Choose WLAN >...
  • Page 40 Configuration Guide Wi-Fi Network Settings 2.16 Configuring XPress (1) Go to the configuration page:  Method 1: Choose WLAN > Wi-Fi > Wi-Fi Settings. Select the target Wi-Fi.  Method 2: Choose WLAN > Wi-Fi > Wi-Fi List. Select the target Wi-Fi in the list and click Edit in the action column.
  • Page 41 Configuration Guide Wi-Fi Network Settings  Method 2: Choose WLAN > Wi-Fi > Wi-Fi List. Select the target Wi-Fi in the list and click Edit in the action column. (2) Click Expand, select a scheduled time span to turn on Wi-Fi and click Save. Clients will be allowed to access the Internet only in the specified time span.
  • Page 42 Configuration Guide Network Settings Network Settings Note This chapter takes the currently logged in device as an example to describe the entry of each function setting page. If you need to configure other devices in the network, please refer to the following path to enter the configuration page of the corresponding device, and then configure the function.
  • Page 43 Configuration Guide Network Settings 3.1.4 Viewing Device Role Choose WLAN > APs > Manage > Device Overview > Device Info. If the self-organizing network is enabled, you can view the device role on the Device Details page. Primary AP/AC: The device can manage downlink devices. Secondary AP/Device: The device has been managed by an AC.
  • Page 44 Configuration Guide Network Settings The device supports the following Internet connection types:  DHCP: The current device will act as a DHCP client and apply for the IPv4 address/prefix from the upstream network device.  Static IP: If this Internet connection type is selected, you need to manually configure a static IPv4 address, subnet mask, gateway address, and DNS server.
  • Page 45 Configuration Guide Network Settings (3) Switch to the Port VLAN tab page and configure VLANs for the port. Click the option box below the port, select the mapping between a VLAN and the port from the drop-down list box, and click Save. ○...
  • Page 46 Configuration Guide Network Settings Caution Changing the MAC address will disconnect the device from the network. You need to reconnect the device to the network or restart the device. Exercise caution when performing this operation. Changing the MTU Choose WLAN > APs > Manage > Network > WAN > WAN. WAN interface MTU indicates the maximum transmission unit (MTU) allowed by the WAN interface.
  • Page 47 Configuration Guide Network Settings Configuring Port Flow Control Choose WLAN > APs > Manage > Advanced > Port Settings. When the LAN ports work at different rates, data congestion may occur, which can slow down the network speed and affect the Internet access experience. Enabling port flow control can help mitigate this problem. Configuring the AP LAN Port Caution This configuration takes effect only on APs with a LAN port.
  • Page 48 Configuration Guide Network Settings Configuring the Optical Transceiver Choose WLAN > APs > Manage > Network > Optical Transceiver Info. The Optical Transceiver Info page displays the optical port connection status of the device. Table 3-1 Optical Transceiver Parameters Parameter Description Temperature (°...
  • Page 49 With Reyee VoIP gateway and Ruijie Reyee App or Ruijie Cloud, VoIP system construction and quick deployment and acceptance can be achieved in hotels and apartments.
  • Page 50 Configuration Guide Network Settings 3 can receive calls from phone 0 at the same time. The phones connected in parallel arrays can also communicate with each other during a voice call. That is, phones 1, 2, and 3 can communicate with each other during a voice call to voice phone 0.
  • Page 51 Configuration Guide Network Settings Table 3-2 Extension Configuration Parameters Parameter Description Extension Number Extension number. Each extension is assigned a unique extension number. Authentication Name Authentication ID. The authentication name can be the same as the extension number or set in a project. Authentication Password Authentication password.
  • Page 52 Configuration Guide Network Settings Parameter Description Voice Gateway Server IP address (or domain name) and port number of the voice gateway server Voice VLAN VLAN ID for voice service (Range: 2–4094) SIP Transport Protocol Ensure that SIP messages are transmitted correctly across the network by choosing the right transmission protocol, either UDP or TCP: UDP: Suitable for most real-time interactive...
  • Page 53 Configuration Guide System Settings System Settings Setting the Login Password  SON mode: Choose Network > Password.  Standalone mode: Choose System > Login > Login Password. Enter the old password and new password. After saving the configuration, use the new password to log in. Caution In self-organizing network mode, the login password of all devices in the network will be changed synchronously.
  • Page 54 Configuration Guide System Settings  Standalone mode: Choose System > Login > Session Timeout. If no operation is performed on the Web interface within a period of time, the session is automatically disconnected. When you need to perform operations again, enter the password to log in again. The default timeout duration is 3600 seconds, that is, 1 hour.
  • Page 55 Configuration Guide System Settings Configuring Reboot Caution  Do not cut off power during system reboot to avoid device damage.  Do not refresh the page or close the browser during the reboot. After the device is successfully rebooted and the Web service becomes available, the device automatically jumps to the login page. ...
  • Page 56 Configuration Guide System Settings 4.4.2 Rebooting All Devices on the Network Choose Network > Reboot & Reset > Network Management. Click Reboot, select All Devices, and click Reboot All Device to reboot all devices in the current network. Caution It takes time to reboot all devices in the current network. The action may affect the whole network. Please be cautious.
  • Page 57 Configuration Guide System Settings Configuring Scheduled Reboot Confirm that the system time is accurate to avoid network interruption caused by device reboot at wrong time. For details about how to configure the system time, see Setting and Displaying System Time. To configure scheduled reboot for the current device, choose Network >...
  • Page 58 Configuration Guide System Settings Configuring Backup and Import Choose WLAN > APs > Manage > System > Backup > Backup & Import. Configuration backup: Click Backup to generate a backup configuration and download the configuration file to the local device. Configuration import: Click Browse, select a backup file on the local PC, and click Import to import the configuration file.
  • Page 59 Configuration Guide System Settings Caution This operation will all configuration of the current device and restart the device. If you want to retain the current configuration, back up the configuration first (see Configuring Backup and Import). Exercise caution when performing this operation. 4.7.2 Restoring All Devices to Factory Settings Choose Network >...
  • Page 60 Configuration Guide System Settings Caution This operation will clear all existing settings of all devices on the network and restart the devices. Exercise caution when performing this operation. Checking the System Version and Performing System Upgrade Caution  You are advised to back up the configuration before performing software upgrade. ...
  • Page 61 Configuration Guide System Settings Switching System Language Choose in the upper right corner of the Web page. Click a language in the drop-down list as the language of the web interface. 4.10 Configuring LED Status Control Caution In standalone mode (when the self-organizing network discovery function is disabled), the LED Status Control function cannot be enabled.
  • Page 62 Configuration Guide Network Diagnosis Tools Network Diagnosis Tools Network Check When a network error occurs, you can perform Network Check to identify the fault and take the suggested action. (1) Click the icon on the right of the navigation bar or choose Diagnostics > Network Check and go to the Network Check page.
  • Page 63 Configuration Guide Network Diagnosis Tools (3) If a network problem is detected, the detection result and handling suggestions are displayed. You can refer to the suggestions to troubleshoot the fault. Network Tools Choose WLAN > APs > Manage > Diagnostics > Network Tools. ...
  • Page 64 Configuration Guide Network Diagnosis Tools Alerts Choose WLAN > APs > Manage > Diagnostics > Alarms. The Alert List page displays possible problems on the network environment and device. All types of alarms are followed by default. You can click Unfollow in the Action column to unfollow a type of alarm. Caution After a type of alarm is unfollowed, all alarms of this type will not be displayed.
  • Page 65 Configuration Guide Network Diagnosis Tools Click View Unfollowed Alarm to view the unfollowed alarm. You can follow the alarm again by clicking Re- follow in the pop-up window. Fault Collection Choose WLAN > APs > Manage > Diagnostics > Fault Collection. When an unknown fault occurs on the device, you can collect fault information on this page.
  • Page 66 Configuration Guide Network Diagnosis Tools...
  • Page 67 Configuration Guide FAQs FAQs Fail to Log In to the Web Interface (1) Check that the Ethernet cable is properly connected to the LAN port of the device. (2) Before accessing the setup page, you are advised to choose Auto for the device enabled with DHCP service to assign an IP address to the PC.
