- Page 1 Quick Installation Guide RG- AP220 Series Wireless Access Device...
- Page 2 Ruijie Networks reserves all copyrights of this document. Any reproduction, excerption, backup, modification, transmission, translation or commercial use of this document or any portion of this document, in any form or by any means, without the prior written consent of Ruijie Networks is prohibited.
-
Page 4: Table Of Contents
Content AP Quick Installation Guide ..................4 Install Wireless AP ..................... 4 1.1.1 Safety Precautions.................. 4 1.1.2 Install Wireless AP .................. 4 Check Device Status ..................6 1.2.1 POE Power Supply ................. 6 1.2.2 Adapter Power Supply ................7 1.2.3 Check Power-on Status ................ -
Page 5: Ap Quick Installation Guide
AP Quick Installation Guide Install Wireless AP 1.1.1 Safety Precautions To guarantee the normal operation and longer service life of wireless AP, please observe the following precautions: Please put the device in a ventilated place; Avoid exposure to hot environment; Keep the device away from high-voltage cables;... - Page 6 1.1.2.1 Install Pipe and Screws During installation, please use screws and pipe of recommended size, as shown below: Straight-through expansion pipe: M7x￠4.5x28 (mm) Screw: 4 * 20PABC (mm) Fig 1. The screw Fig 2. The pipe 1.1.2.2 Mounting Steps Mounting steps are shown below: The size and depth of four wall-mounting holes drilled on the wall shall be determined according to the size of mounting pipe and screws selected.
-
Page 7: Check Device Status
Fig 3. Align the three holes at the bottom of wireless AP to with the three studs of brackets and then pull the AP towards the wall-mounting screw for 8mm, as shown in Fig 3. Secure this screw until reaching the side hole of AP. If the AP is mounted on vertical surface, the bracket end with screw shall be the bottom side. -
Page 8: Adapter Power Supply
Fig 4. 1.2.2 Adapter Power Supply When using adapter power supply, please use the adapter recommend by our company. 1.2.3 Check Power-on Status After the AP is powered, if the device works normally, the STATUS LED will blink green, and then stop blinking after 30 seconds (see 2 in Fig. 5). The RADIO LED will light up green when AP works at 2.4G (see 1 and 3 in Fig. - Page 9 3. The user cannot find AP A. First follow the abovementioned two steps. B. Check whether the AP is properly configured. C. Adjust the angle of AP's antenna. D. Move the client device of mobile user and adjust the distance between client device and AP.
- Page 10 MODIFICATION: Any changes or modifications not expressly approved by the grantee of this device could void the user’s authority to operate the device.
