Operating Guide | VLT® Decentral Drive FCD 302
If an output filter is connected to the motor, select [2] Enable reduced AMA.
l
Refer to
6.9.1 Introduction to Warnings and Alarms
l
occur.
Run this procedure on a cold motor for best results.
l
6.6.2 Running AMA
Enter the advanced motor data in parameter group 1–3* Adv. Motor Data.
1.
Select [Main Menu] to access parameters.
2.
Scroll to parameter group 1–** Load and Motor and press [OK].
3.
Scroll to parameter group 1–2* Motor Data and press [OK].
4.
Scroll to parameter 1–29 Automatic Motor Adaptation (AMA) and press [OK].
5.
Select [1] Enable complete AMA and press [OK].
6.
Follow the on-screen instructions.
The test runs automatically and indicates when it is complete.
6.7 Local Control Test
To reset the drive after a trip, see
1.
Press [Hand On] to provide a local start command to the drive.
2.
Accelerate the drive by pressing [▲] to full speed. Moving the cursor left of the decimal point provides quicker input changes.
3.
Note any acceleration problems.
4.
Press [Off]. Note any deceleration problems.
6.8 System Start-up
The procedure in this section requires wiring and application programming to be completed. The following procedure is recommended
after application setup is completed.
If warnings or alarms occur, see
1.
Press [Auto On].
2.
Apply an external run command.
3.
Adjust the speed reference throughout the speed range.
4.
Remove the external run command.
5.
Check the sound and vibration levels of the motor to ensure that the system is working as intended.
6.9 Warnings and Alarms
6.9.1 Introduction to Warnings and Alarms
A warning or an alarm is signaled by the relevant front indicator lights of the drive and indicated by a code on the display. The 6 front
indicator lights show the actual status of the drive. For a status description of the 6 front indicator lights, refer to
Lights.
A comprehensive list of all warnings and alarms for the VLT® Decentral Drive FCD 302 is found in the VLT® AutomationDrive FC 301/302
Programming Guide. The following list highlights a selection of the most frequently occurring alarms and warnings encountered during
drive operation.
46
| Danfoss A/S © 2025.04
or VLT® AutomationDrive FC 301/302 Programming Guide if warnings or alarms
6.9.1 Introduction to Warnings and
6.9.1 Introduction to Warnings and
Alarms.
Alarms.
Operating the Drive
6.3 Front Indicator
AQ267036816112en-000301 / 130R0208
